4-Person Cross-Shaped Modular Office Cubicle Workstation with Mobile Pedestals (model WS-CUB-4P-CORNER-01) is listed under L-Shaped Office Desk. Dimensions: 2800 × 2800 × 1200 mm. Materials: 25mm E1 grade particleboard with light oak melamine laminate, wear-resistant 0.6mm top layer. Load capacity: 100 kg. Product Features: Modular,cubicle,structure,4-person,seating,integrated,mobile,storage,fabric,privacy,panels. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | Fanshidun | Model | WS-CUB-4P-CORNER-01 |
| Overall dimensions (W × D × H) | 2800 × 2800 × 1200 mm | Primary Component Thickness | 40 mm according to load-bearing role |
| Hardware / Moving-part Clearance | 5 mm operating clearance | Total unit weight | 420 kg |
| Worksurface static load capacity | 100 kg | Recommended maximum user weight per seat | 136 kg |
| Partition panel sound attenuation | 20 dB | Mobile pedestal caster rolling load rating | 40 kg |
| Standard warranty period | 5 years | Available color option count | 4 |
| Reference Static Load | 150 kg depending on category | Moving-part Durability Reference | Acceptance target 50000 cycles |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years | Worksurface board | 25mm E1 grade particleboard with light oak melamine laminate, wear-resistant 0.6mm top layer |
| Partition frame | 1.2mm thick powder-coated dark grey square steel tubing, welded corner connections | Lower partition panel | 9mm thick MDF core wrapped in sage green fabric, tackable surface for notes |
| Upper partition panel | Perforated steel mesh panel with matching powder coat, framed by steel tubing | Mobile pedestal cabinet body | 18mm E1 grade particleboard with matching light oak melamine, sage green drawer front |
| Pedestal casters | Black nylon swivel casters, 360-degree rotation, 2 lockable brakes per unit | Desk modesty panel | 18mm melamine-faced particleboard matching worksurface finish, mounted under desk front |
| Drawer lock mechanism | Zinc alloy cam lock with keyed entry, one key per pedestal | Worksurface edge banding | 2mm thick PVC edge banding, impact-resistant, color-matched to worksurface |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | Reference Finish / Color Count | Recommended 6finish options |
| 4-person independent workspace layout | Cross-shaped partition arrangement creates 4 separate L-shaped corner workstations with visual privacy between users | Lockable mobile pedestal storage | Each seat includes one rolling 1-drawer 1-open cabinet unit that fits fully under the worksurface, lockable top drawer for secure storage |
| Semi-open upper partition design | Perforated mesh upper panel allows overhead light transmission and partial visibility while blocking direct line of sight between seated users | Tackable partition surface | Fabric-wrapped lower partition panels accept push pins for hanging notes, documents, or small office accessories |
| Curved inner worksurface edge | Radiused corner cut on each L-shaped workstation eliminates sharp hip contact when entering or exiting the seat | Modular reconfiguration capability | Bolt-connected steel frame system allows disassembly and reconfiguration into different cubicle layouts as office needs change |
| Cable routing access | Pre-punched cable access grommets at worksurface corners allow routing of power and data cables from floor to desktop | Locking caster function | Two lockable casters per mobile pedestal prevent unintended movement when the storage unit is positioned under the desk |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Packaging Volume | 0.8 m³/set |
| Reference Packaged Gross Weight | 120 kg/set | Open plan office space | Designed for corporate open offices to create 4 dedicated private work zones while maintaining collaborative accessibility |
| Small business startup workspace | Ideal for 50person teams to set up structured individual work areas without permanent wall construction | Call center or back office operations | Suitable for high-density task work with seated privacy and integrated storage for work materials, reducing cross-worker distraction |
| Government or administrative office | Meets standard commercial durability requirements for long-term daily use in public sector work environments | Temporary project team space | Reconfigurable modular design allows quick setup and rearrangement for short-term project teams or flexible co-working spaces |
| Recommended seating configuration | Pair with standard mid-back ergonomic office chairs with seat height 520 mm to match 750mm worksurface height | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2800 × 2800 × 1200 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total unit weight | 420 kg | |
|---|---|---|
| Worksurface static load capacity | 100 kg | |
| Recommended maximum user weight per seat | 136 kg | |
| Partition panel sound attenuation | 20 dB | |
| Mobile pedestal caster rolling load rating | 40 kg | |
| Standard warranty period | 5 years | |
| Available color option count | 4 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worksurface board | 25mm E1 grade particleboard with light oak melamine laminate, wear-resistant 0.6mm top layer | |
|---|---|---|
| Partition frame | 1.2mm thick powder-coated dark grey square steel tubing, welded corner connections | |
| Lower partition panel | 9mm thick MDF core wrapped in sage green fabric, tackable surface for notes | |
| Upper partition panel | Perforated steel mesh panel with matching powder coat, framed by steel tubing | |
| Mobile pedestal cabinet body | 18mm E1 grade particleboard with matching light oak melamine, sage green drawer front | |
| Pedestal casters | Black nylon swivel casters, 360-degree rotation, 2 lockable brakes per unit | |
| Desk modesty panel | 18mm melamine-faced particleboard matching worksurface finish, mounted under desk front | |
| Drawer lock mechanism | Zinc alloy cam lock with keyed entry, one key per pedestal | |
| Worksurface edge banding | 2mm thick PVC edge banding, impact-resistant, color-matched to worksurface | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| 4-person independent workspace layout | Cross-shaped partition arrangement creates 4 separate L-shaped corner workstations with visual privacy between users | |
|---|---|---|
| Lockable mobile pedestal storage | Each seat includes one rolling 1-drawer 1-open cabinet unit that fits fully under the worksurface, lockable top drawer for secure storage | |
| Semi-open upper partition design | Perforated mesh upper panel allows overhead light transmission and partial visibility while blocking direct line of sight between seated users | |
| Tackable partition surface | Fabric-wrapped lower partition panels accept push pins for hanging notes, documents, or small office accessories | |
| Curved inner worksurface edge | Radiused corner cut on each L-shaped workstation eliminates sharp hip contact when entering or exiting the seat | |
| Modular reconfiguration capability | Bolt-connected steel frame system allows disassembly and reconfiguration into different cubicle layouts as office needs change | |
| Cable routing access | Pre-punched cable access grommets at worksurface corners allow routing of power and data cables from floor to desktop | |
| Locking caster function | Two lockable casters per mobile pedestal prevent unintended movement when the storage unit is positioned under the desk | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office space | Designed for corporate open offices to create 4 dedicated private work zones while maintaining collaborative accessibility | |
|---|---|---|
| Small business startup workspace | Ideal for 50person teams to set up structured individual work areas without permanent wall construction | |
| Call center or back office operations | Suitable for high-density task work with seated privacy and integrated storage for work materials, reducing cross-worker distraction | |
| Government or administrative office | Meets standard commercial durability requirements for long-term daily use in public sector work environments | |
| Temporary project team space | Reconfigurable modular design allows quick setup and rearrangement for short-term project teams or flexible co-working spaces | |
| Recommended seating configuration | Pair with standard mid-back ergonomic office chairs with seat height 520 mm to match 750mm worksurface height |
EU Market Access Requirements* EN Standards
| Office furniture ergonomic requirements | EN 527:2011 | |
|---|---|---|
| Office furniture safety requirements | EN 14073:2004 |
US and Canada office-furniture standards
| Office desk performance standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Office storage unit standard | ANSI/BIFMA X2019 | |
| Office panel system standard | ANSI/BIFMA X2016 |
Standards applicable to China-market projects
| Office desk dimensional standard | GB/T 3326 | |
|---|---|---|
| Wood-based panel formaldehyde emission | GB 18580 | |
| Furniture surface durability | GB/T 4893.8 | |
| Metal furniture structural stability | GB/T 24821 |
This product must meet the following technical requirements: 1. Office desk dimensional standard: GB/T 3326; 2. Wood-based panel formaldehyde emission: GB 18580; 3. Furniture surface durability: GB/T 4893.8; 4. Metal furniture structural stability: GB/T 24821; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
