PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3600 × 2400 × 1100 mm
Overall footprint	3600 x 2400 x 1100 mm
Per-seat worksurface dimensions	1200 x 600 mm
Worksurface height from floor	750 mm
Partition panel total height	1100 mm
Under-desk seated knee clearance height	670 mm
Partition panel thickness	45 mm
Worksurface panel thickness	25 mm
Individual mobile pedestal dimensions	420 x 480 x 725 mm
Metal support frame tube thickness	1.5 mm
Leveler foot adjustment range	20 mm
Cable grommet diameter	60 mm
Caster wheel diameter	50 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total workstation net weight (reference)	280 kg
Per-seat worksurface static load capacity	100 kg
Seating capacity	6 users
Melamine surface abrasion resistance	2000 cycles
Warranty period	5 years
Available finish options	30 colors
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Worksurface substrate	25mm thick E1-grade melamine faced particleboard (MFC)
Worksurface edge banding	2mm thick PVC edge trim, impact-resistant
Partition frame	1.5mm thick powder-coated dark gray steel
Partition privacy panel	Sage green tackable polyester fabric over fiberboard core
Partition top section	Horizontal slatted steel grille with matching powder coat
Partition lower modesty panel	Light oak grain fluted MFC panel
Mobile pedestal body	Light oak grain fluted MFC construction with lockable drawers
Mobile pedestal drawer front	Sage green MFC with integrated key lock and label holder
Pedestal casters	50mm black nylon twin-wheel swivel casters
Frame feet	Adjustable nylon leveler feet with threaded steel insert
Cable grommets	Matte black ABS plastic circular cable ports
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Modular layout configuration	Cross-shaped 6-station interlocking assembly
Seated privacy screening	1100mm tall fabric dividers block direct line of sight between adjacent seats
Cable management	One circular grommet per worksurface routes power and data cables from desk to floor
Mobile storage	Lockable 3-drawer pedestal per station rolls on casters for flexible positioning
Floor leveling	Threaded leveler feet adjust to compensate for uneven office flooring
Knock-down assembly	Modular bolt-together connectors allow disassembly for relocation or reconfiguration
Tackable partition surface	Fabric partition panels accept push pins for posting notes and documents
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open plan office layouts	Provides divided individual workstations for mid-sized teams
Call center and customer service facilities	Compact cross layout maximizes seat count while maintaining privacy
Startup and co-working spaces	Modular design supports flexible team expansion and reconfiguration
Government and public institution offices	Durable commercial construction supports long-term heavy daily use

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office desk safety and strength	EN 527:2002
Office furniture ergonomic dimensions	EN 527:2011
Office storage cabinet stability	EN 14073:2004

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Office desk performance and durability	ANSI/BIFMA X2021
Mobile storage unit performance	ANSI/BIFMA X2019

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Formaldehyde emission limit	GB/T 39600E1 grade
Desk structural stability	GB/T 3326
Office furniture human ergonomics	GB/T 39223
Coating adhesion on metal frames	GB/T 9286

Standardized tender description text

This product must meet the following technical requirements:
1. Formaldehyde emission limit: GB/T 39600E1 grade;
2. Desk structural stability: GB/T 3326;
3. Office furniture human ergonomics: GB/T 39223;
4. Coating adhesion on metal frames: GB/T 9286;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · CUB-6P-CROSS-SG-LW

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · CUB-6P-CROSS-SG-LW

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · CUB-6P-CROSS-SG-LWOpen Export Tool

Quick Actions

Post an RFQ

Product Description

This 6-Person Cross-Shaped Modular Office Cubicle Workstation is a clustered partition desk solution designed to balance collaborative accessibility and individual privacy for shared work environments. Built in an interlocking cross-shaped layout, it arranges six dedicated workstations around a central structural core, with fabric privacy partitions rising to separate adjacent seats and block direct seated line of sight. Each workstation is paired with a matching mobile pedestal, creating a cohesive, organized visual profile that blends soft sage green fabric accents, light oak grain textured panels, and dark gray steel framing for a modern, professional aesthetic suitable for a range of work settings. The worksurfaces are constructed from 25mm thick E1-grade melamine faced particleboard, finished with impact-resistant 2mm PVC edge trim to withstand regular daily use. The supporting frame uses powder-coated steel, with partition panels featuring a tackable sage green polyester fabric surface over fiberboard core, a horizontal slatted steel grille at the top section, and a light oak grain fluted melamine modesty panel at the lower section. Each mobile storage pedestal is built from fluted light oak grain melamine, with lockable three-drawer storage, sage green drawer fronts fitted with integrated key locks and label holders, and black nylon twin-wheel swivel casters for easy repositioning. Threaded leveler feet are integrated into the base to adjust for uneven flooring. Functionally, the workstation delivers dedicated workspace for six users, with each seat fitted with a circular cable grommet to route power and data cables neatly from the worksurface to the floor. The tackable fabric partition surfaces accept push pins for posting notes, schedules, and reference documents, while the lockable mobile pedestals offer secure, flexible personal storage that can be positioned to suit individual user preference. Its bolt-together knock-down assembly allows straightforward disassembly for office relocations or layout reconfigurations, supported by modular connectors that simplify future adjustments. This workstation is well suited for open plan office layouts supporting mid-sized teams, call center and customer service facilities where compact, high-density seating with privacy is required, startup and co-working spaces that need flexible setups to accommodate team growth and changing workflows, and government or public institution offices where durable construction supports long-term heavy daily use. For procurement, stakeholders can select from 30 available finish options to align with existing interior design schemes. The product is unbranded, and comes with a 5-year warranty. Assembly takes 40 minutes per set, with each unit shipped across two cartons, so teams should plan for appropriate installation staffing and storage space for delivered packages prior to setup. The modular design also allows for coordinated expansion by adding matching units as team headcount grows, making it a scalable choice for growing organizations.

6-Person Cross-Shaped Modular Office Cubicle Workstation with Mobile Pedestals Specifications
