Single-Person Partitioned Office Workstation with Mobile Pedestal (model WS-SGL-PED-1206) is listed under L-Shaped Office Desk, with overall dimensions of 1200 × 600 × 1100 mm and main material of Particle‑board (PB). Load capacity: 100 kg. Certifications: Modular,workstation,integrated,partition,mobile,storage,pedestal,light,oak,finish. This page consolidates 6 groups of specifications and ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Workstation total net weight | 58 kg | |
| Recommended user weight limit | 120 kg | |
| Adjustable foot vertical adjustment travel | 15 mm | |
| Surface abrasion resistance rating | 2000 cycles | |
| Partition panel sound attenuation | 12 dB | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop panel | 18mm thick melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Structural frame | Powder-coated white square steel tube with adjustable leveling feet | |
| Partition infill panels | Lower melamine-faced wood-look panel, upper fabric-wrapped acoustic panel | |
| Pedestal drawer fronts | 16mm melamine-faced particleboard with white metal pull handles | |
| Drawer slides | Cold-rolled steel three-quarter extension ball-bearing slides | |
| Pedestal casters | 30mm diameter swivel nylon casters with total lock function |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Pre-drilled desktop grommet with under-desk cable tray to route power and data cords | |
|---|---|---|
| Pedestal locking | Centralized key lock securing all three pedestal drawers for personal storage security | |
| Keyboard support | Pull-out under-desk keyboard tray positioned at ergonomic typing height | |
| Floor leveling | Adjustable steel feet on all frame base points to stabilize unit on uneven flooring |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office layouts | Single-seat workstation providing visual privacy and dedicated storage for individual employees | |
|---|---|---|
| Call center and administrative work areas | Compact footprint and cable management support computer and telephony equipment setup |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
