Automatic mm / inch conversion · Core engineering specifications
| Overall installed dimensions | 1200 x 600 x 1200 mm | |
|---|---|---|
| Desk work surface height | 750 mm | |
| Desk top thickness | 25 mm | |
| Total partition height from floor | 1200 mm | |
| Lower solid partition panel height | 900 mm | |
| Upper frosted slatted screen height | 300 mm | |
| Partition panel thickness | 30 mm | |
| Under-desk knee clearance height | 670 mm | |
| Knee clearance width | 700 mm | |
| Mobile pedestal dimensions | 450 x 500 x 660 mm | |
| Cable grommet diameter | 60 mm | |
| Leveling foot adjustment range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total product net weight | 80 kg | |
|---|---|---|
| Maximum desk top static load capacity | 100 kg | |
| Mobile pedestal drawer static load | 25 kg | |
| Mobile pedestal cabinet shelf load | 30 kg | |
| Caster rolling load rating per unit | 40 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Recommended user capacity | 1 person | |
| Product structural warranty | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desk work surface | 25mm E1-grade melamine-faced particleboard, anti-scratch, water-resistant | |
|---|---|---|
| Partition structural frame | 1.2mm thick silver anodized aluminum extrusion framing | |
| Lower partition panels | 18mm melamine-faced particleboard, light beige front, dark grey modesty side | |
| Upper privacy screens | 5mm thick frosted slatted translucent acrylic panels | |
| Mobile pedestal body | 0.8mm thick cold-rolled steel with powder-coated finish, light beige door, grey drawer front | |
| Mobile pedestal casters | 50mm diameter nylon twin-wheel office casters, 2 lockable | |
| Desk support frame | 1.5mm thick powder-coated steel square tube understructure | |
| Cable grommets | ABS plastic round desk grommets with brush insert | |
| Adjustable leveling feet | Nylon base with steel threaded stem, mounted on frame bottom corners | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| 3-sided wrap-around privacy partition | Provides seated visual privacy, reduces cross-desk distraction for individual users | |
|---|---|---|
| Cable management grommets | Two rear-corner pass-throughs route power and data cables from desk to floor | |
| Lockable mobile pedestal storage | Integrated lock secures upper drawer and lower cabinet, rolls for flexible under-desk placement | |
| Adjustable leveling feet | Rotating feet compensate for uneven floors to keep work surface stable and level | |
| Frosted slatted upper screen | Translucent panels allow ambient light transmission while blocking direct line of sight | |
| Modular knock-down connection system | Aluminum post and bracket assembly allows reconfiguration into multi-seat clusters | |
| Front modesty panel | Solid dark grey panel blocks view of seated user's legs from front approach | |
| Smooth rolling pedestal movement | Twin-wheel casters allow pedestal to slide in/out under desk without floor damage | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff workstations | Modular design allows clustered layout for team work areas with individual privacy | |
|---|---|---|
| Startup and small business office setups | Cost-effective functional workstation includes built-in storage for small team deployment | |
| Call center and administrative work areas | Seated height and privacy screens reduce distraction for focused task work | |
| Temporary project office spaces | Knock-down design allows fast assembly and reconfiguration for short-term workspaces | |
| Government and enterprise staff zones | Durable commercial construction meets daily high-traffic office use requirements | |
| Co-working dedicated desk stations | Allocated individual workspaces with lockable storage for personal and work items |
EU Market Access Requirements* EN Standards
| EN 527-2:2002 | Office worktables safety and strength requirements, applicable to desk structural performance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture dimensions reference for seated work surface clearance requirements | |
| EN 12521:2015 | Furniture strength, durability and safety requirements for commercial storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Mobile storage pedestal performance standard for drawer and caster durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk top and panel components | |
|---|---|---|
| GB/T 3327-2023 | Office desk performance test methods, applicable to structural load and stability validation | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade minimum requirement | |
| GB/T 24821-2023 | Office furniture panel partition systems, applicable to cubicle screen structure |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk top and panel components; 2. GB/T 3327-2023: Office desk performance test methods, applicable to structural load and stability validation; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade minimum requirement; 4. GB/T 24821-2023: Office furniture panel partition systems, applicable to cubicle screen structure; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
