Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation footprint | 1650 x 1650 mm | |
|---|---|---|
| Main desktop height | 760 mm | |
| Main worktop size | 1500 x 610 mm | |
| Return worktop size | 1500 x 610 mm | |
| Desktop thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Partition panel total height | 1500 mm | |
| Partition solid lower panel height | 1200 mm | |
| Partition translucent upper screen height | 300 mm | |
| Partition panel thickness | 60 mm | |
| Pull-out keyboard tray size | 640 x 300 mm | |
| Knee well height clearance | 680 mm | |
| Knee well depth clearance | 460 mm | |
| Mobile pedestal size | 400 x 500 x 680 mm | |
| Overhead open shelf depth | 300 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 91 kg | |
|---|---|---|
| Drawer slide load rating | 45 kg per drawer | |
| Drawer slide cycle rating | 50000 cycles | |
| Mobile pedestal caster load rating | 30 kg per caster | |
| Recommended user weight capacity | 136 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm E0-grade engineered wood with thermally fused melamine laminate | |
|---|---|---|
| Edge banding | 2mm thick impact-resistant PVC edging on all exposed wood edges | |
| Partition lower panels | 60mm thick MFC core with matte green laminate finish | |
| Partition upper screens | Translucent frosted louvered panels with silver aluminum frame | |
| Frame and connectors | Powder-coated steel modular interlocking brackets and supports | |
| Mobile pedestal | Melamine laminated engineered wood body, steel ball-bearing slides, dual-wheel nylon casters |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Keyboard tray mechanism | Retractable under-desk slide-out tray with smooth steel glides, stows flush under desktop | |
|---|---|---|
| Mobile pedestal storage | 3-drawer configuration (2 box drawers, 1 lockable file drawer) with single key lock for all drawers | |
| Cable management system | Desktop grommet with integrated under-desk cable raceway for separated power and data routing | |
| Partition system | Modular interlocking panels with reconfigurable connection points for layout adjustment |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office single staff workstations | Provides partial acoustic and visual privacy for focused individual work in shared office spaces | |
|---|---|---|
| Call center and administrative staff seating | L-shaped layout supports computer work, document handling, and adjacent reference material placement |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office worktables safety and strength requirements, applicable to desktop and frame performance verification | |
|---|---|---|
| EN 1335-2:2018 | Office furniture office chairs safety requirements, applicable to matched seating compatibility verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard, applicable to commercial workstation load and durability verification | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units safety and performance standard, applicable to mobile pedestal durability verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to worktop and cabinet durability verification | |
|---|---|---|
| GB/T 10357.1-1989 | Furniture mechanical performance test for desks, applicable to static load and stability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worktop and cabinet durability verification; 2. GB/T 10357.1-1989: Furniture mechanical performance test for desks, applicable to static load and stability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
