Automatic mm / inch conversion · Core engineering specifications
| Primary Component Thickness | 40 mm according to load-bearing role | |
|---|---|---|
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Per-desktop static vertical load capacity | 120 kg | |
|---|---|---|
| Recommended maximum user weight per station | 120 kg | |
| Total workstation assembly net weight | 260 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Formaldehyde emission grade | E1 | |
| Partition panel flame retardant grade | B1 | |
| Drawer slide cycle durability | 50000 cycles | |
| Leveling foot maximum load per foot | 80 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm thick E1 grade particle board, melamine impregnated paper facing, 2mm PVC edge banding | |
|---|---|---|
| Partition support frame | 30mm wide silver anodized aluminum alloy extrusion frame | |
| Partition infill panels | 16mm thick light green matte laminate panel with off-white lower panel section | |
| Lower modesty panel | 16mm thick off-white melamine faced particle board, matching desktop finish | |
| Mobile pedestal cabinet body | 0.8mm thick cold-rolled steel with epoxy powder coated off-white finish | |
| Mobile pedestal casters | 30mm diameter black nylon swivel casters, 2 with brake function | |
| Pedestal drawer slides | Cold-rolled steel full extension ball bearing drawer slides | |
| Desk support feet | Nylon base adjustable leveling feet with steel screw thread | |
| Pedestal lock | Zinc alloy central cam lock securing all drawers, with 2 keys per cabinet | |
| Cable grommets | Black ABS plastic round wire management grommets on each desktop | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Seated visual privacy | 1200mm tall partitions block direct cross-seat line of sight for seated users | |
|---|---|---|
| Cable management | 60mm diameter desktop grommets route power/data cables below work surface to floor channels | |
| Mobile storage access | Lockable 3-drawer mobile pedestals roll out from under desk for open access, lock into place for security | |
| Floor leveling adjustment | 15mm travel adjustable feet compensate for uneven office floors to keep desktops stable and level | |
| Modular reconfiguration | Aluminum frame partition system supports disassembly and re-layout into alternate workstation shapes | |
| Pedestal drawer operation | Top stationery drawer and 2 lower file drawers operate on full-extension ball bearing slides for full access | |
| Surface maintenance | Melamine desktop and panel surfaces resist water, stains and scratches for easy daily cleaning | |
| Anti-tip stability | Interconnected partition frame structure and base feet prevent tipping under normal seated use and lateral force | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Largest carton outer dimensions | 1300 x 650 x 120 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan general office space | Provides divided individual work positions for 4 staff to reduce visual distraction in open offices | |
|---|---|---|
| Small team department workspace | Suitable for 4-person administrative, finance or operations teams requiring individual work surfaces | |
| Startup and co-working flexible offices | Modular knock-down design supports easy relocation and layout changes for flexible workspaces | |
| Call center and back office processing areas | Low partitions provide privacy without blocking supervisor line of sight for operational oversight | |
| Temporary project team spaces | Quick assembly and disassembly supports short-term project team work area setup | |
| Office renovation and fit-out projects | Standard size matches commercial office floor modules for bulk procurement in fit-out projects |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for commercial use | |
|---|---|---|
| EN 1335-1:2020 | Office work chair dimensional reference for matching knee clearance and work height | |
| EN 1023-1:2019 | Office storage furniture safety requirements applicable to mobile pedestal cabinets |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Office desk strength, durability and stability requirements for general office use | |
|---|---|---|
| ANSI/BIFMA X5.6-2022 | Office panel systems cubicle performance and safety requirements | |
| ANSI/BIFMA X5.3-2020 | Vertical file cabinet performance requirements applicable to mobile pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desktop and panel components | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor use | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to desktop strength and stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktop and panel components; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor use; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to desktop strength and stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
