Automatic mm / inch conversion · Core engineering specifications
| Overall cluster footprint | 2800 x 2400 x 1100 mm | |
|---|---|---|
| Per-station main work surface length | 1500 mm | |
| Per-station work surface depth | 600 mm | |
| Work surface height from floor | 750 mm | |
| Partition panel total height | 1100 mm | |
| Knee clearance height under desk | 600 mm | |
| Knee well curved cutout width | 700 mm | |
| Mobile 3-drawer pedestal dimensions | 400 x 500 x 600 mm | |
| Desktop panel thickness | 25 mm | |
| Partition lower panel thickness | 16 mm | |
| PVC edge banding thickness | 1 mm | |
| Cable grommet diameter | 60 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Per-work-surface static load capacity | 100 kg | |
|---|---|---|
| Mobile pedestal drawer static load per drawer | 25 kg | |
| Per-station recommended user weight capacity | 150 kg | |
| Product net weight per complete cluster | 145 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Surface water and stain resistance | Grade 4 | |
| Recommended user capacity | 2 people | |
| Frame corrosion resistance coating thickness | 60 um | |
| Product warranty period | 10 years | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface core | 25mm thick MFC engineered wood | |
|---|---|---|
| Work surface finish | Light oak thermofused melamine laminate | |
| Edge protection | 1mm thick PVC edge banding | |
| Partition frame | White powder-coated square steel tubing | |
| Partition lower panels | 16mm thick light oak MFC panels | |
| Partition upper section | Semi-transparent frosted acrylic panels | |
| Mobile pedestals | 16mm thick MFC cabinet with white drawer fronts | |
| Drawer slides | Cold-rolled steel 3-section full-extension slides | |
| Pedestal casters | 50mm diameter nylon swivel casters | |
| Cable grommets | ABS plastic cable management inserts | |
| Mounting hardware | Zinc-plated steel connectors and brackets | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Privacy partition separation | 1100mm high dividers block direct line of sight between adjacent users | |
|---|---|---|
| Mobile pedestal storage | 3-drawer wheeled unit slides under desk surface for flexible filing and supply storage | |
| Desktop cable management | Integrated 60mm grommet routes monitor and power cables below the work surface | |
| Modular assembly | Knock-down steel frame connects to pre-drilled wood panels with standard fasteners | |
| Drawer operation | Full-extension slides allow 100% access to rear drawer contents for file retrieval | |
| Floor level adjustment | Integrated adjustable feet on partition frames compensate for uneven office flooring | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Two-seat modular cluster fits standard open office grid layouts for team seating | |
|---|---|---|
| Small business administrative offices | Compact footprint provides dedicated work space for two support staff | |
| Startup office flexible work zones | Reconfigurable modular design supports changing team size and layout needs | |
| Shared co-working space dedicated desks | Partitioned semi-private stations suit assigned seating in co-working environments | |
| Call center agent workstations | Semi-privacy dividers reduce visual distraction without blocking team communication |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and performance requirements for work surfaces | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements for mobile drawer pedestals | |
| EN 1335-1:2020 | Office furniture ergonomic reference for knee clearance dimensions |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard for commercial office workstations | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for mobile filing pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to work surfaces and cabinet components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel partition frames | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to MFC work surface core material | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to work surfaces and cabinet components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel partition frames; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to MFC work surface core material; 4. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
