Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2820 x 1600 x 1200 mm | |
|---|---|---|
| Working surface height | 750 mm | |
| Per-position work surface depth | 700 mm | |
| Divider partition total height | 1150 mm | |
| Divider partition thickness | 40 mm | |
| Desktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Per-station storage pedestal dimensions | 420 x 460 x 650 mm | |
| Seated knee clearance height | 700 mm | |
| Knee clearance width per position | 600 mm | |
| Lower modesty panel height | 400 mm | |
| Upper mesh screen height | 350 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total set net weight | 100 kg | |
|---|---|---|
| Static load per work surface | 120 kg | |
| Maximum supported user weight per station | 150 kg | |
| Drawer static load capacity | 25 kg | |
| Cabinet shelf static load | 30 kg | |
| Surface scratch resistance | 2000 cycles | |
| Surface stain resistance level | Grade 4 | |
| Design service life | 10 years | |
| Warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | E1 grade melamine-faced particleboard, 25mm thick, light oak woodgrain finish | |
|---|---|---|
| Desk edge banding | 2mm thick impact-resistant PVC, matched to oak woodgrain color | |
| Divider frame | Dark powder-coated aluminum alloy, rectangular profile | |
| Upper divider section | Dark breathable mesh screen with acoustic dampening properties | |
| Lower divider section | Sage green melamine-faced MFC solid privacy panel | |
| Storage pedestal bodies | Light oak woodgrain melamine-faced particleboard, fluted front cabinet doors | |
| Storage drawer fronts | Sage green melamine-faced MFC with recessed black pull handle | |
| Support legs | Dark powder-coated tapered steel legs, 30mm diameter, with adjustable leveling feet | |
| Modesty panels | Light oak melamine-faced particleboard fixed under desk edges | |
| Hardware components | Zinc-plated steel connecting fittings, nylon adjustable glides | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Two 60mm diameter plastic desk grommets, one per work surface, with under-desk cable raceway | |
|---|---|---|
| Storage configuration per station | One upper utility drawer above one closed-door storage cabinet, integrated at outer desk end | |
| Leveling adjustment | 15mm vertical adjustment range on all leg feet to compensate for uneven floors | |
| Privacy separation | 1150mm high partition blocks direct line of sight between seated adjacent users | |
| Modular connection | Interlocking aluminum frame allows connection to additional workstation modules for larger office layouts | |
| Assembly design | Knock-down flat-pack construction with cam-lock fasteners for on-site assembly | |
| Storage lock compatibility | Drawer fitted with standard cam lock provision for securing personal office items | |
| Surface performance | Melamine finish resists water rings, coffee stains, and abrasion from regular office use | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office spaces | Creates defined 2-person work zones without full wall construction in open offices | |
|---|---|---|
| Small business team work areas | Provides private dedicated workspace for two adjacent team members with shared corner access | |
| Administrative and back-office departments | Offers sufficient work surface and storage for paperwork, computers and daily office tasks | |
| Startup office fit-outs | Modular design allows cost-effective rapid deployment of multi-seat office layouts | |
| Co-working space dedicated desks | Provides semi-private fixed work positions with lockable storage for members | |
| Corporate departmental workgroups | Can be connected to additional modules to form larger team clusters of 4, 6 or more seats | |
| Recommended matching furniture | Pair with mid-back ergonomic office chairs, monitor arms and under-desk CPU holders |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables, safety and structural performance requirements for commercial use | |
|---|---|---|
| EN 1335-1:2020 | Office furniture reference for workstation ergonomic clearance dimensions | |
| EN 14073-2:2004 | Office storage furniture, safety and structural requirements for integrated pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, static load and durability testing for work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, structural performance for integrated drawers and cabinets |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel structural performance | |
|---|---|---|
| GB/T 3327-2016 | Performance standards for office desks and work tables, dimensional and load requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel structural performance; 2. GB/T 3327-2016: Performance standards for office desks and work tables, dimensional and load requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
