Automatic mm / inch conversion · Core engineering specifications
| Overall cluster footprint | 3600 x 3600 x 750 mm | |
|---|---|---|
| Partition divider height | 450 mm | |
| Partition divider thickness | 83 mm | |
| Per-station work surface | 1200 x 600 mm | |
| Knee clearance height under worktop | 680 mm | |
| Knee clearance width at front cutout | 600 mm | |
| Worktop panel thickness | 25 mm | |
| Pedestal drawer unit dimensions | 400 x 500 x 650 mm | |
| CPU tray dimensions | 250 x 450 mm | |
| Cable grommet diameter | 60 mm | |
| Pedestal drawer interior depth | 450 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total unit net weight (engineering ) | 380 kg | |
|---|---|---|
| Worksurface static load capacity per station | 100 kg | |
| Pedestal drawer static load per drawer | 25 kg | |
| Recommended maximum user weight per station | 120 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Surface water resistance rating | Level 2 | |
| Supported user count | 6 persons | |
| Factory warranty period | 6 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | 18mm particleboard core | |
|---|---|---|
| Worktop finish | Light oak effect melamine laminate | |
| Worktop edge banding | 2mm PVC edge trim | |
| Frame and partition rails | 1.8mm thick white powder-coated steel | |
| Partition divider panels | 25mm white melamine-faced particleboard | |
| Pedestal cabinet panels | 16mm white melamine particleboard | |
| Drawer slides | Cold-rolled steel 3-section full-extension slides | |
| CPU support trays | 1.2mm thick white powder-coated steel | |
| Cable grommets | ABS plastic with brushed metal finish cap | |
| Feet and levelers | Nylon adjustable glide feet | |
| Drawer handles | White ABS integrated pull handles | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | 3 lockable drawers per fitted pedestal | |
|---|---|---|
| Cable management | 1 desktop grommet per station plus under-desk routing | |
| CPU support | Fixed under-desk steel tray per outer station | |
| Partition privacy function | Low 450mm dividers separate adjacent work zones | |
| Modular assembly | Knock-down steel connector system | |
| Desk leveling | Adjustable nylon glides on all support legs | |
| Knee access design | Curved front cutout per L-shaped station | |
| Drawer operation | Full-extension steel slides with soft-close damping | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office spaces | Designed for 6 staff in call centers, admin teams or back-office departments, balancing privacy and collaboration | |
|---|---|---|
| Startup and co-working spaces | Modular layout allows quick deployment and reconfiguration for flexible team sizes | |
| Small business office fit-outs | All-in-one cluster includes storage, cable management and CPU support for turnkey installation | |
| Staff work areas requiring partial privacy | Low dividers reduce distraction without blocking natural light or supervisor visibility | |
| Seated computer-based work roles | Ergonomic 750mm work height supports standard office chairs and desktop/laptop use | |
| Flooring types | Suitable for carpet, vinyl and tile office floors with adjustable leveling glides for stable placement |
EU Market Access Requirements* EN Standards
| EN 527-2:2016 | Office worktables safety and strength requirements, applicable to structural load and stability testing | |
|---|---|---|
| EN 527-3:2003 | Office worktables test methods for stability and mechanical strength, recommended for acceptance testing | |
| EN 13986:2004 | Wood-based panels for construction, applicable to particleboard substrate performance requirements | |
| Worksurface height | 750 mm |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desk products standard, applicable to static load, fatigue and stability performance requirements | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to pedestal drawer load and cycle durability testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel cabinet and desk components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frame and hardware components | |
| GB/T 35607-2017 | Green product assessment standard for furniture, recommended for low-VOC material procurement |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel cabinet and desk components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and hardware components; 3. GB/T 35607-2017: Green product assessment standard for furniture, recommended for low-VOC material procurement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
