Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total workstation static load capacity | 300 kg | |
|---|---|---|
| Applicable user count | 3 users | |
| total workstation net weight | 185 kg | |
| Work surface abrasion resistance reference | 2000 cycles | |
| Product design service life | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 18mm thick particle board with light oak melamine veneer | |
|---|---|---|
| Privacy divider frame | 25mm thick black powder-coated MDF edging | |
| Screen insert panel | 4mm thick frosted semi-transparent acrylic | |
| Pedestal drawer fronts | 16mm thick melamine-faced particle board with silver plastic pull handles | |
| Visitor chair support frame | 12mm diameter chrome-plated steel cantilever frame | |
| Visitor chair upholstery | Breathable black polyester mesh back and fabric seat | |
| Desktop support structure | 1.2mm thick powder-coated steel cross braces | |
| Pedestal casters | 50mm diameter hard nylon swivel casters | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Workstation layout | Three linearly arranged independent work zones separated by dual-sided privacy screens | |
|---|---|---|
| Under-desk storage | Mobile 3-drawer pedestal assigned to each work position, slides fully under desktop | |
| Cable management | Recessed cable access grommet at corner of each work surface | |
| Visitor seating | Cantilever mesh chair positioned at each work zone, no wheel casters for guest stability | |
| Divider configuration | Screens mounted along desk edges and between seats, fixed at 120 degree angles for sightline blocking | |
| Pedestal mobility | Swivel casters on base of each storage pedestal allow repositioning | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 9 | |
|---|---|---|
| Largest carton dimensions | 2450 x 700 x 120 mm | |
| Total shipping gross weight | 220 kg | |
| Total shipment volume | 0.95 CBM | |
| On-site assembly time | 120 minutes | |
| 20ft container loading quantity | 28 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons |
Recommended spaces / users / usage modes
| Open-plan corporate offices | Dedicated separated workstations for 3 employees with integrated storage, reduces open office distraction | |
|---|---|---|
| Startup team workspaces | Compact linear layout fits small office footprints with visitor seating for impromptu discussions | |
| Shared co-working spaces | Modular configuration supports assigned or hot-desking use with uniform privacy separation | |
| Government service offices | Clear screen separation between staff and visiting public for professional interaction |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
