Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 1400 x 1100 mm | |
|---|---|---|
| Desktop height from floor | 750 mm | |
| Desktop thickness | 25 mm | |
| Privacy divider height above desktop | 350 mm | |
| Lower side panel height from floor | 650 mm | |
| Divider panel thickness | 32 mm | |
| Knee clearance width under desktop | 800 mm | |
| Knee clearance height under desktop | 650 mm | |
| Mobile pedestal dimensions | 400 x 480 x 650 mm | |
| Frame tube wall thickness | 1.2 mm | |
| PVC edge banding thickness | 2 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Caster load rating per wheel | 25 kg | |
| Workstation net weight | 48 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Recommended user capacity | 1 person | |
| Product warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | E1 grade melamine-faced particleboard | |
|---|---|---|
| Support frame | White powder-coated square steel tube | |
| Upper privacy panels | Light wood-tone melamine board | |
| Lower modesty panels | White melamine-faced engineered board | |
| Edge banding | 2mm thick PVC edging | |
| Mobile pedestal body | Melamine-faced engineered board | |
| Pedestal casters | 50mm diameter hard plastic swivel wheels | |
| Drawer glides | Full-extension steel ball-bearing slides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Privacy screening | Three-sided wraparound dividers block line of sight from adjacent work areas | |
|---|---|---|
| Mobile storage pedestal | Rolling under-desk unit with lockable upper drawer and lower storage compartment | |
| Leveling adjustment | Integrated adjustable feet on desk frame corners | |
| Cable management | Rear panel routing channel and desktop grommet | |
| Freestanding installation | No permanent wall fixing required for setup | |
| Pedestal mobility lock | Two front casters include locking brakes | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office space | Creates individual private work zones in shared commercial office environments | |
|---|---|---|
| Home office setup | Provides dedicated, distraction-free workspace for remote work and study | |
| Startup and co-working spaces | Modular freestanding design allows flexible layout reconfiguration as team size changes | |
| Call center workstations | Low-height dividers reduce visual distraction while enabling supervisor visibility |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance validation | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to mobile pedestal performance | |
| EN 13722:2004 | Office furniture - Work desks dimensional stability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for static load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to mobile pedestal performance validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and panel components | |
|---|---|---|
| GB/T 3327-2017 | Performance standards for office desks and workstations, applicable for structural stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for engineered wood panels, applicable to board material acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and panel components; 2. GB/T 3327-2017: Performance standards for office desks and workstations, applicable for structural stability testing; 3. GB 18580-2017: Formaldehyde emission limits for engineered wood panels, applicable to board material acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
