PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2800 × 1320 × 1100 mm
Work surface height from floor	750 mm
Single seat work surface area	1200 x 600 mm
Knee clearance height under desk	650 mm
Per-seat storage pedestal dimensions	400 x 400 x 600 mm
Low divider frame height above desk	350 mm
Work surface panel thickness	25 mm
Cabinet panel thickness	16 mm
Edge banding thickness	2 mm
Steel frame wall thickness	1.8 mm
Cable grommet diameter	60 mm
Pedestal foot clearance height	100 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Assembled product weight	100 kg
Work surface static load capacity	150 kg
Drawer slide cycle rating	50000 cycles
Cabinet door hinge cycle rating	80000 cycles
Surface abrasion resistance	2000 cycles
Recommended user capacity	4 people
Commercial warranty period	5 years
Total under-pedestal cable tray load	10 kg
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	E1-grade melamine-faced particleboard, 25mm thick, water/scratch resistant
Edge banding	2mm thick PVC impact-resistant edging, bonded to all desktop edges
Divider and support frame	1.8mm thick powder-coated white steel, open frame construction
Cabinet carcass	16mm thick MDF panel, off-white matte finish
Cabinet door panels	16mm thick MDF, light wood-look melamine finish matching work surface
Drawer fronts	16mm thick MDF, off-white matte finish with integrated key lock
Pedestal base legs	1.2mm thick black powder-coated steel, elevated open frame
Hardware accessories	Zinc-plated steel screws, connectors, and lock cylinders
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness	2 mm
Metal Frame Wall Thickness	2 mm cold-rolled steel
Primary Connector Specification	Reference M6-M8 with at least 2 fixing points per main support

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Per-seat storage configuration	1 lockable upper drawer + 1 lower hinged cabinet door per position
Privacy divider function	350mm high open steel frame dividers separate adjacent seated positions
Cable management	60mm diameter desktop grommets route power/data cables to under-desk space
Modular reconfiguration	Bolted steel frame connectors allow rearrangement or expansion of the workstation cluster
Lockable storage	Integrated key locks secure upper drawers for personal office item storage
Elevated pedestal design	100mm floor clearance under pedestals supports easy cleaning and cable routing
Edge protection	2mm PVC edging prevents impact damage to desk and cabinet panel edges
Stable support structure	Steel frame cross-bracing eliminates wobble during daily office work
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open plan office spaces	Suitable for 4 staff members in collaborative or departmental work zones
Coworking facilities	Provides dedicated individual work spots with basic private storage
Start-up and small business offices	Cost-effective modular solution for growing team seating requirements
Corporate administrative departments	Meets daily office work needs for paperwork, laptop use, and document storage
Staff training work areas	Stable work surfaces and integrated storage support training material organization

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office work tables safety and strength requirements, applies to structural performance
EN 527-2:2016	Office work tables dimensional and mechanical safety requirements
EN 13722:2004	Office furniture storage units strength and durability requirements

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk products performance and durability standard for commercial office use
ANSI/BIFMA X5.9-2019	Storage units performance standard for pedestal cabinet components
ANSI/BIFMA M7.1-2020	Formaldehyde and VOC emission testing for office furniture systems

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to panel desk components
GB/T 3327-2016	Performance requirements for office desks and workstations, applies to structural load rating
GB 18580-2017	Formaldehyde emission limits for wood-based panels, applies to E1-grade board materials
GB/T 4897-2015	Specification for particleboard used in furniture construction

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel desk components;
2. GB/T 3327-2016: Performance requirements for office desks and workstations, applies to structural load rating;
3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applies to E1-grade board materials;
4. GB/T 4897-2015: Specification for particleboard used in furniture construction;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFW-4P-LD-2813

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFW-4P-LD-2813

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFW-4P-LD-2813Open Export Tool

Quick Actions

Post an RFQ

Product Description

This unbranded model OFW-4P-LD-2813 modular 4-person face-to-face office workstation delivers a balanced blend of open collaboration and individual work space for commercial settings. Its two-tone light wood and white finish creates a bright, contemporary visual profile, with a symmetric face-to-face layout that positions four workstations across the shared frame. Low 350mm powder-coated white steel open-frame dividers sit between adjacent seats, defining personal work zones without blocking cross-team sightlines or natural light flow. Each 1200 x 600mm individual work surface sits at a 750mm floor height, with 650mm of knee clearance underneath for comfortable seated use. The workstation is built for long-term commercial durability. 25mm thick E1-grade melamine-faced particleboard work surfaces offer water and scratch resistance, finished with 2mm thick impact-resistant PVC edge banding on all desktop edges to prevent chipping from daily impact. Support frames use 1.8mm thick powder-coated steel, while integrated under-desk storage pedestals are constructed from 16mm MDF: cabinet carcasses and drawer fronts feature an off-white matte finish, with cabinet door panels matching the light wood tone of work surfaces. Pedestal bases use 1.2mm thick black powder-coated steel legs, with all hardware constructed from zinc-plated steel. The 100kg assembled unit supports 150kg of static load per work surface, with drawer slides rated for 50000 open-close cycles, hinges rated for 80000 cycles, and surface abrasion resistance rated for 2000 cycles, backed by a 5-year commercial warranty. Each seat includes a dedicated 400 x 400 x 600mm storage pedestal with one lockable upper drawer secured by an integrated key lock for personal items, and one lower hinged cabinet for larger document storage. 60mm desktop cable grommets route power and data cords cleanly to the under-desk area, while 100mm floor clearance under elevated pedestals supports easy floor cleaning and unobstructed cable runs. Bolted steel frame connectors allow simple reconfiguration or expansion of the cluster as team needs change. The workstation is well-suited for open-plan office collaborative zones, coworking facilities, start-up and small business offices, corporate administrative departments, and staff training work areas, supporting daily laptop use, paperwork, and training material organization for four users. For procurement, note that each set ships across multiple cartons with a total packaged gross weight of 180kg and 1 cubic meter of packaging volume, requiring 40 minutes of assembly time per unit. The modular bolted design allows for future layout adjustments, making it a flexible choice for growing teams that require consistent, functional seating without unnecessary visual enclosure.

4-Person Face-to-Face Modular Office Workstation with Low Dividers and Integrated Pedestals Specifications
