Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation dimensions | 2400 x 2400 x 1200 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static load capacity per work surface | 100 kg | |
|---|---|---|
| Total workstation net weight | 280 kg | |
| Recommended maximum user weight per seat | 130 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 18mm thick melamine-faced particleboard, scratch-resistant matte finish | |
|---|---|---|
| Partition frame | 1.2mm thick extruded aluminum alloy, silver anodized finish | |
| Partition lower panel | 9mm thick MDF core with dark green fabric upholstery | |
| Partition upper louver | 1.2mm thick polycarbonate slats, frosted translucent finish | |
| Mobile pedestal body | 15mm thick melamine-faced particleboard, lockable steel drawer slides | |
| Structural hardware | Powder-coated steel support brackets and leveler feet, nylon swivel casters |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular connection | Interlocking aluminum frame connectors support reconfiguration of seat count | |
|---|---|---|
| Cable management | Under-desk power strip mounting rail and desktop cable grommets route wiring out of sight | |
| Mobile storage | Lockable 3-drawer pedestals on casters slide fully under desk for space saving | |
| Pull-out keyboard tray | Ball-bearing slide tray retracts flush under desk front when not in use |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office spaces | Creates defined private work zones for four staff while preserving collaborative sightlines | |
|---|---|---|
| Call center and administrative offices | Integrated power and cable management supports daily computer-based task work |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office worktables safety and strength requirements, applicable to desk structural performance | |
|---|---|---|
| EN 1335-2:2018 | Office furniture strength requirements, applicable to load-bearing workstation components |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desktops and storage pedestals | |
|---|---|---|
| GB/T 3327-2016 | Technical requirements for office desks, applicable to work surface and structural strength | |
| GB/T 35607-2017 | Green product assessment for furniture, applicable to formaldehyde emission limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktops and storage pedestals; 2. GB/T 3327-2016: Technical requirements for office desks, applicable to work surface and structural strength; 3. GB/T 35607-2017: Green product assessment for furniture, applicable to formaldehyde emission limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
