Automatic mm / inch conversion · Core engineering specifications
| Overall cluster footprint | 2800 x 2800 x 1200 mm | |
|---|---|---|
| Per-seat worktop size | 1800 x 1400 mm | |
| Work surface height | 750 mm | |
| Total partition height | 1200 mm | |
| Partition panel thickness | 60 mm | |
| Under-desk knee clearance height | 650 mm | |
| Mobile pedestal dimensions | 420 x 460 x 650 mm | |
| Upper partition slat height | 300 mm | |
| Lower solid partition section height | 900 mm | |
| Worktop thickness | 25 mm | |
| Caster diameter for mobile pedestals | 50 mm | |
| Work surface grommet diameter | 60 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total set net weight | 260 kg | |
|---|---|---|
| Per worktop static load capacity | 100 kg | |
| Pedestal drawer static load per drawer | 25 kg | |
| Number of supported staff | 3 people | |
| Partition frame connection cyclic durability | 10000 assembly cycles | |
| Pedestal caster rolling durability | 20000 rolling cycles | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Standard product warranty | 3 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm E1 grade melamine-faced chipboard | |
|---|---|---|
| Partition lower panel | Fabric-wrapped fiberboard with beige/taupe finish | |
| Partition upper panel | Slotted steel mesh with silver metallic frame | |
| Partition support frames | Anodized aluminum alloy extrusions | |
| Worktop support legs | Powder-coated cold-rolled steel square tubing | |
| Mobile pedestal body | 18mm E1 grade melamine-faced particleboard | |
| Pedestal casters | Polypropylene swivel casters with brake tabs | |
| Drawer locks | Zinc alloy keyed cam locks, 2 keys per unit | |
| Modesty panels between stations | Matching melamine-faced hardboard | |
| Cable grommets | ABS plastic flush-mount desk grommets | |
| Partition connection hardware | Zinc-plated steel cam lock fasteners | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Modular panel assembly | Connects via pre-installed cam locks for reconfigurable cluster layouts | |
|---|---|---|
| Mobile pedestal storage | 3 drawers per station, lockable top drawer for secure office supply storage | |
| Caster mobility for pedestals | 4 swivel casters per unit, 2 with locking brakes for fixed positioning | |
| Cable management access | 1 surface grommet per worktop for routing monitor/power cords to under-desk channels | |
| Seated visual privacy | 1200mm partition height blocks direct line of sight between seated adjacent users | |
| Freestanding installation | No wall attachment required, leveled via adjustable base glides on partition feet | |
| Tackable lower partition surface | Fabric-covered panels accept push pins for posting notes and documents | |
| Color customization option | Neutral beige and grey two-tone finish compatible with standard office palettes | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office zones | 3-person work cluster for team departments with moderate acoustic and visual privacy | |
|---|---|---|
| Startup and corporate workspaces | Suitable for administrative, operational, and support staff seating arrangements | |
| Call center and back-office areas | Compact layout provides dedicated work surfaces and personal storage without excess footprint | |
| Co-working flexible spaces | Freestanding installation allows rearrangement as team sizes change | |
| Recommended paired accessories | Ergonomic office task chairs, monitor arms, and under-desk cable trays |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to desk surfaces | |
|---|---|---|
| EN 1335-1:2020 | Office furniture dimensional safety for seated workstations, applicable to clearance dimensions | |
| EN 71-3:2019 | Safety of furniture surface material migration, applicable to all accessible components | |
| EN 1022:2018 | Domestic and office seating stability reference, applicable to pedestal stability testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to worktop load and durability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to mobile pedestal testing | |
| ANSI/BIFMA X5.6-2022 | Panel systems performance standard, applicable to partition strength and connections |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and pedestal components | |
|---|---|---|
| GB/T 3327-2018 | Performance and test standards for office desks, applicable to worktop load and stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture | |
| GB/T 10357.1-2013 | Furniture mechanical property test for tables, applicable to worktop strength testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and pedestal components; 2. GB/T 3327-2018: Performance and test standards for office desks, applicable to worktop load and stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture; 4. GB/T 10357.1-2013: Furniture mechanical property test for tables, applicable to worktop strength testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
