2-Person 120-Degree Curved Corner Office Cubicle Workstation with Mobile Pedestals (model CW-2P-120D-WS) is listed under L-Shaped Office Desk, with overall dimensions of 2400 × 1800 × 1200 mm and main material of Particle‑board (PB). Load capacity: 113 kg. Certifications: Modular,construction,2-seat,cluster,green,and,white,finish,low,privacy,dividers,mobile,lockable,storage. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cluster dimensions | 2400 x 1800 x 1200 mm | |
|---|---|---|
| Work surface height | 760 mm | |
| Per-user curved work surface size | 1500 x 1200 mm | |
| Work surface thickness | 25 mm | |
| Modesty panel height below desk | 400 mm | |
| Partition divider total height | 1200 mm | |
| Frosted upper partition section height | 400 mm | |
| Fabric lower partition section height | 800 mm | |
| Partition frame profile thickness | 30 mm | |
| Seated under-desk knee clearance height | 690 mm | |
| Under-desk knee clearance depth | 600 mm | |
| Mobile pedestal dimensions | 400 x 500 x 660 mm | |
| Cable grommet diameter | 60 mm | |
| Caster diameter on mobile pedestals | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static load capacity per work surface | 113 kg | |
|---|---|---|
| Mobile pedestal drawer static load | 25 kg per drawer | |
| Total workstation net weight (without chairs) | 145 kg | |
| Leveling foot adjustment range | 15 mm | |
| Design per-user seating capacity | 1 person per work surface | |
| Commercial surface wear resistance | 10000 abrasion cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm E1-grade particleboard with thermally fused white laminate, 1mm PVC edge banding | |
|---|---|---|
| Partition frame | Powder-coated dark gray steel square extrusion framing | |
| Lower partition panel | 6mm MDF core wrapped in green tackable woven office fabric | |
| Upper partition panel | 5mm frosted translucent acrylic privacy panel | |
| Modesty panel | 18mm black laminated particleboard | |
| Mobile pedestal cabinet | 18mm white laminated particleboard with steel drawer slides, integrated key lock, nylon casters |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Wire management | Surface-mounted cable grommets and under-desk raceways route power and data cords from desktop to floor | |
|---|---|---|
| Mobile storage mobility | 3-drawer pedestals roll on 5 casters, 2 of which lock to prevent unintended movement when positioned under desk | |
| Modular reconfiguration | Bolt-together partition connectors allow cluster expansion or layout rearrangement without permanent wall fixing | |
| Floor leveling | Adjustable feet on partition bases and desk legs compensate for uneven office flooring to eliminate wobble |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff work areas | Provides individual semi-private work zones without full height wall construction, supporting high-density team seating | |
|---|---|---|
| Small business team expansion layouts | Modular connectors allow adding additional 120-degree stations as team size grows |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables safety and strength requirements for work surface components | |
|---|---|---|
| EN 1335-2:2018 | Office furniture work chairs safety requirements for paired seating if supplied as bundle | |
| EN 14073-2:2004 | Office storage furniture safety requirements for mobile pedestal cabinets |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for mobile pedestal drawer performance and lock function |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate desk and pedestal components | |
|---|---|---|
| GB/T 35607-2017 | Limits of harmful substances for office furniture, applicable to board and adhesive materials | |
| GB/T 24821-2009 | Office desk performance test methods for structural stability and load capacity |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate desk and pedestal components; 2. GB/T 35607-2017: Limits of harmful substances for office furniture, applicable to board and adhesive materials; 3. GB/T 24821-2009: Office desk performance test methods for structural stability and load capacity; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
