PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2400 × 1200 × 1200 mm
Overall footprint (W x D x H)	2400 x 1200 x 1200 mm
Work surface height	750 mm
Privacy partition thickness	32 mm
Individual work surface width per station	1200 mm
Work surface depth per station	600 mm
Knee clearance height under desk	620 mm
Mobile pedestal dimensions (W x D x H)	404 x 500 x 595 mm
Upper partition slatted vent height	200 mm
Modesty panel height	400 mm
Caster diameter on mobile pedestals	50 mm
Work surface thickness	25 mm
Edge banding thickness	2 mm
Knee clearance width per seat	600 mm
Partition frame profile thickness	30 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total workstation static load capacity	300 kg
Recommended maximum user weight per station	120 kg
Seating capacity	2 people
Work surface abrasion resistance	2000 cycles
Product net weight	135 kg
Warranty period	5 years
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	E1 grade melamine-faced particleboard (MFC) with 2mm PVC edge banding
Partition panel core	18mm thick medium density fiberboard (MDF)
Partition upholstery	Woven polyester fabric in sage green finish
Partition frame	Powder-coated dark gray steel extrusion
Upper partition vent section	Perforated slatted steel panel with matching powder coat
Mobile pedestal body	16mm thick light oak and sage green melamine laminate MDF
Mobile pedestal drawers	Full-extension cold-rolled steel drawer slides
Drawer lock	Integrated keyed cam lock, one key per pedestal
Casters on pedestals	Dual-wheel polyurethane casters, two with locking brake
Modesty panels	16mm thick light oak melamine MDF
Hardware fasteners	Zinc-plated steel bolts and cam lock connectors
Cable management grommets	60mm diameter plastic desk grommets

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Privacy division	Full-height fabric partitions separate adjacent workstations
Mobile storage	Two caster-mounted lockable 3-drawer pedestals fit under each desk
Cable routing	Desk surface grommets route power and data cables below work surface
Drawer locking	Central key lock secures all drawers on each mobile pedestal
Anti-tilt protection	Mobile pedestals include anti-tilt mechanism for single drawer opening
Modular reconfiguration	Partition frames use standard cubicle connection hardware
Caster locking	Two lockable casters per pedestal hold units in fixed position
Surface maintenance	Stain-resistant melamine surface wipes clean with standard office cleaners
Vented partition airflow	Upper slatted partition sections allow cross-ventilation between stations
Flat-pack assembly	Knock-down construction uses standard cam and bolt fasteners
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office staff areas	Provides individual privacy and dedicated storage for two adjacent employees
Administrative and finance departments	Secure lockable storage for documents and stable work surface for computer work
Small business startup offices	Compact two-person layout maximizes space efficiency in limited floor plans
Co-working space dedicated desks	Fixed partitioned stations offer semi-private work areas for long-term members
Call center and back-office operations	Vented partitions reduce noise transfer while supporting dense seating layouts
Temporary project team spaces	Modular construction allows reconfiguration as team sizes change
Educational institution administrative offices	Durable commercial grade construction withstands high daily use

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office work tables, safety and strength requirements for work surfaces
EN 1335-1:2020	Office furniture dimensions reference for seated workstation clearance
EN 14073-2:2004	Storage furniture strength and stability for office pedestals

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk products performance and durability testing standard
ANSI/BIFMA X5.9-2019	Storage units performance standard for mobile office pedestals

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to MFC/MDF panel components
GB/T 3327-2016	Stability and mechanical performance requirements for office desks and tables
GB 18580-2017	Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor use
GB/T 4897.3-2003	Performance requirements for particleboard used in furniture construction

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MFC/MDF panel components;
2. GB/T 3327-2016: Stability and mechanical performance requirements for office desks and tables;
3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor use;
4. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture construction;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-2P-L-SG-OAK-001

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-2P-L-SG-OAK-001

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-2P-L-SG-OAK-001Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Two-Person L-Shaped Modular Office Cubicle Workstation with Mobile Pedestals (model WS-2P-L-SG-OAK-001, unbranded) is a partitioned two-seat workspace solution designed for flexible, privacy-focused office layouts. Its L-shaped configuration occupies a 2400 x 1200 x 1200 mm footprint, with two equal individual workstations each measuring 1200 mm wide and 600 mm deep, set at a standard 750 mm work surface height with 620 mm of under-desk knee clearance. Full-height 32 mm thick partitions separate the two stations, framed in powder-coated dark gray steel extrusion and upholstered in soft sage green woven polyester fabric over an 18 mm MDF core; a 200 mm tall perforated slatted steel vent section at the upper partition edge supports gentle air circulation while preserving visual and acoustic separation. Light oak and light beige laminate finishes across storage elements complement the sage upholstery for a calm, professional aesthetic. Work surfaces are constructed from E1 grade melamine-faced MFC with 2mm PVC edge banding, delivering 2000 cycles of abrasion resistance and supporting a total static load of 300 kg, with a recommended maximum user weight of 120 kg per station. Two included mobile pedestals, measuring 404 x 504 x 595 mm, are built from 16mm light oak and sage green melamine laminate MDF, fitted with full-extension cold-rolled steel drawer slides, an integrated keyed cam lock that secures all three drawers per unit, an anti-tilt mechanism that allows only one drawer to open at a time, and dual-wheel polyurethane casters (two with locking brakes per pedestal) that let the units tuck fully under each desk when not in use. Desk surface grommets enable tidy routing of power and data cables below the work surface, and standard cubicle connection hardware on partition frames supports easy modular reconfiguration as spatial needs shift. This workstation is well-suited for open-plan office staff areas, administrative and finance departments requiring secure document storage, small business startup offices seeking space-efficient layouts, co-working space dedicated long-term member desks, call center and back-office operations supporting dense seating, and temporary project team spaces that need flexible reconfiguration. Procurement teams should note the unit ships as one set across two cartons, requires 40 minutes of assembly per set, carries a 5-year warranty, and has a net weight of 135 kg. No custom finish options are offered for this base model, and all connection hardware is included for standard modular cubicle setups.

Two-Person L-Shaped Modular Office Cubicle Workstation with Mobile Pedestals Specifications
