Automatic mm / inch conversion · Core engineering specifications
| Overall cluster dimensions | 2800 x 2800 x 1100 mm | |
|---|---|---|
| Desk work surface height | 750 mm | |
| Per-person L-workstation side length | 1400 mm | |
| Work surface depth at straight edge | 600 mm | |
| Knee well vertical clearance | 650 mm | |
| Knee well arched opening width | 800 mm | |
| Partition total height from floor | 1100 mm | |
| Drawer pedestal dimensions | 400 x 500 x 600 mm | |
| Under-desk footrest shelf depth | 300 mm | |
| Cable grommet diameter | 60 mm | |
| Worktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Partition lower panel thickness | 16 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Worktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Recommended user count | 4 | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Unit net weight reference | 260 kg | |
| Warranty period under normal use | 5 years | |
| Available color option count | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panels | 25mm E1 grade melamine-faced particle board | |
|---|---|---|
| Frame and partition framing | 1.2mm thick powder-coated white steel | |
| Partition upper sections | Frosted translucent acrylic panels | |
| Partition lower sections | 16mm melamine-faced particle board | |
| Edge trim | 2mm thick impact-resistant PVC edging | |
| Drawer pedestals | 18mm melamine-faced particle board with light gray drawer fronts | |
| Drawer slides and locks | Cold-rolled steel ball-bearing slides with keyed locks | |
| Footrest shelves | 16mm melamine-faced particle board with steel supports | |
| Cable grommets | ABS plastic with brushed finish cover | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Semi-privacy partition layout | Cross-arranged 1100mm high screens separate 4 work positions | |
|---|---|---|
| Drawer pedestal storage | One 3-drawer lockable mobile pedestal per workstation | |
| Cable management system | 60mm desktop grommets route power/data cables to under-desk space | |
| Arched knee well design | Concave curved cutout at each seating position | |
| Integrated footrest shelves | Fixed raised shelf at outer edge of each workstation | |
| Modular assembly structure | Knock-down CKD construction with bolted frame connections | |
| Smooth drawer operation | Ball-bearing full-extension slides for all drawers | |
| Worktop surface protection | Scratch, stain and heat resistant melamine coating | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Cluster layout accommodates 4 employees while maintaining semi-privacy | |
|---|---|---|
| Small startup workspaces | Compact cross footprint maximizes seating density in limited floor space | |
| Call center and admin offices | Modular design supports standardized workstation deployment for large teams | |
| Hybrid work office zones | Semi-height partitions balance focus work and spontaneous team communication | |
| Government and corporate back-office spaces | Durable commercial-grade construction withstands high-frequency daily use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks, safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office furniture - Work tables and desks, safety, strength and durability requirements | |
| EN 1335-1:2020 | Office furniture - Office work chair dimensions, referenced for ergonomic desk height alignment |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applies to strength, durability and structural performance testing | |
|---|---|---|
| ANSI/BIFMA e3-2019e | Furniture sustainability standard, applicable for material emission and lifecycle criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and panel components | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks and worktables, applies to worktop load testing | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of formaldehyde emission for wood furniture | |
| GB/T 4897-2015 | Particle board requirements, applicable to worktop and panel substrate materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and panel components; 2. GB/T 3327-2016: Performance test methods for office desks and worktables, applies to worktop load testing; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission for wood furniture; 4. GB/T 4897-2015: Particle board requirements, applicable to worktop and panel substrate materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
