PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3200 × 2800 × 1200 mm
Overall cluster dimensions	3200 x 2800 x 1200 mm
Individual work surface dimensions per seat	1400 x 700 x 750 mm
Partition total height from floor	1200 mm
Frosted upper slat partition section height	350 mm
Solid lower partition panel height	850 mm
Under-desk seated knee clearance height	720 mm
Mobile under-desk pedestal dimensions	400 x 500 x 600 mm
Partition panel thickness	26 mm
Worktop substrate thickness	25 mm
Leveling foot adjustment range	15 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Per-seat worktop static load capacity	120 kg
Total cluster net weight	240 kg
Recommended maximum user weight per seat	150 kg
Melamine surface scratch resistance	2000 abrasion cycles
Warranty period	5 years
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Worktop substrate	E1 grade high-density particleboard
Worktop surface finish	Matte melamine laminate, scratch/water resistant
Worktop edge banding	2mm thick PVC edging, impact resistant
Partition support frame	Anodized aluminum alloy extrusions
Upper partition panels	Frosted translucent slatted polycarbonate/glass
Lower partition panels	Melamine-faced particleboard privacy panels
Mobile pedestal body	Cold-rolled steel with powder-coated finish
Pedestal casters	50mm diameter hard nylon swivel casters
Frame leveling feet	Nylon base steel threaded adjustable feet
Hardware components	Zinc-plated steel connector bolts and cam locks
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Modular cluster configuration	4 individual seated work positions arranged in cross layout
Privacy partition separation	Upper translucent slats allow light transmission, lower panels block seated sightlines
Mobile under-desk storage	3-drawer lockable rolling pedestal fits under each work surface
Cable management access	1 pre-drilled cable port per worktop for wire routing
Floor leveling adjustment	Threaded feet adjust to compensate for uneven open office flooring
Pedestal mobility	Swivel casters allow pedestal to be pulled out for access or repositioned
Layout reconfiguration	Modular frame connectors support reconfiguration into T/linear/2/6/8 seat layouts
Drawer locking function	Central lock on pedestal secures all drawers for personal storage
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Number of shipping cartons	11 cartons
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open plan office staff work areas	Seated task work for administrative, customer service or operations teams
Call center and shared workspace environments	Privacy dividers reduce distraction while maintaining open light transmission
Small business and startup office layouts	Modular design supports future expansion or layout changes
Government and corporate back-office departments	Durable commercial construction supports daily long-term use
Co-working dedicated desk zones	Lockable personal storage for assigned member workstations

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office work tables safety and strength requirements for work surfaces
EN 1335-1:2020	Office furniture reference for seated clearance dimensions
EN 13722:2004	Office furniture storage units strength and durability for mobile pedestals

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	ANSI/BIFMA X5.5 Desk and Table Products

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to desktop and panel components
GB/T 3327-2017	Technical requirements for furniture desks, applicable to worktop and structure performance
GB 18580-2017	Formaldehyde emission limits for wood-based panels, E1 grade emission requirement
GB/T 24821-2009	Office furniture partition workstation system technical specifications

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktop and panel components;
2. GB/T 3327-2017: Technical requirements for furniture desks, applicable to worktop and structure performance;
3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade emission requirement;
4. GB/T 24821-2009: Office furniture partition workstation system technical specifications;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-CR4-1200-FSL

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-CR4-1200-FSL

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-CR4-1200-FSLOpen Export Tool

Quick Actions

Post an RFQ

Product Description

This 4-Person Cross-Shaped Modular Office Cubicle Workstation, model WS-CR1200-FSL, is an unbranded commercial office cubicle workstation designed for balanced privacy, collaboration, and adaptable workspace planning. Arranged in a cross-shaped cluster, the unit delivers four dedicated work positions with carefully structured visual separation. The 1200mm tall partitions combine an 850mm solid lower panel that blocks direct seated sightlines between adjacent users, and a 350mm frosted translucent upper slat section that permits natural light flow across the cluster, avoiding the closed-in feel of fully opaque dividers. The overall cluster measures 3200 x 2800 x 1200 mm, with each individual work surface sized at 1400 x 700 x 750 mm, offering 720mm of seated under-desk knee clearance for ergonomic comfort.
Construction relies on durable, commercial-grade materials built for daily long-term use. Worktops feature an E1 grade high-density particleboard substrate finished with matte, scratch and water-resistant melamine laminate, rated to withstand 2000 abrasion cycles, finished with 2mm impact-resistant PVC edge banding. Partition support uses anodized aluminum alloy extrusions holding 26mm thick panels, with cold-rolled steel, powder-coated 3-drawer mobile pedestals fitted with 50mm hard nylon swivel casters, and nylon-base steel threaded adjustable leveling feet to compensate for uneven flooring. Each work surface supports 120kg of static load, with a 150kg recommended maximum user weight per seat, and the full cluster carries a 5-year warranty.
Core practical functions include modular frame connectors that allow reconfiguration beyond the cross layout into T-shape, linear, 2-seat, 6-seat, or 8-seat arrangements as needs evolve. Each position has one pre-drilled cable port for neat wire routing, plus a lockable rolling pedestal sized to fit neatly under the desk that slides out for easy access or repositioning. The partition design balances distraction reduction with an open, light-filled feel, making the workstation suitable for open-plan office staff zones for administrative, customer service, or operations teams, call center and shared workspace floors, small business and startup offices, government and corporate back-office departments, and dedicated desk zones in co-working facilities.
When procuring this unit, note that delivery includes 11 shipping cartons, with a reference assembly time of 40 minutes per set and 0.8 cubic meters of packaging volume per set. Consider future layout adjustment needs during initial placement to leverage the modular reconfiguration capability, and confirm floor condition to make full use of the integrated leveling feet for stable installation.
