Single-Person Cubicle Office Workstation Desk with 3-Drawer Mobile Pedestal (model CUB-1S-3DP-TG-LO) is listed under L-Shaped Office Desk, with overall dimensions of 1650 × 1650 × 1200 mm and main material of Particle‑board (PB). Load capacity: 91 kg. Certifications: modular,cubicle,fabric,privacy,dividers,under-desk,storage,pedestal,black,metal,frame. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 1650 x 1650 x 1200 mm | |
|---|---|---|
| Work surface height | 760 mm | |
| Work surface thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Knee clearance height | 670 mm | |
| Knee clearance width | 900 mm | |
| Partition panel thickness | 32 mm | |
| Upper fabric partition height | 700 mm | |
| Lower solid partition height | 420 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Cable grommet diameter | 80 mm | |
| Steel frame section thickness | 1.5 mm | |
| Drawer internal height | 150 mm for top two drawers, 300 mm for bottom file drawer | |
| Leveler adjustment range | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Worktop static load capacity | 91 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Unit net weight | 113 kg | |
| File compatibility | Accommodates letter, legal, A4 size documents | |
| Pedestal caster load rating | 45 kg per caster, total 180 kg for full pedestal | |
| Surface abrasion resistance | 2000 cycles | |
| Manufacturer warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm engineered wood core with thermally fused light oak laminate, 2mm PVC edge band | |
|---|---|---|
| Partition frame | 1.5mm thick powder-coated black steel profile | |
| Upper partition panels | Teal tackable polyester fabric over medium density fiberboard core | |
| Lower partition panels | Gray melamine faced engineered wood modesty panels | |
| Mobile pedestal | Light oak laminate faced engineered wood cabinet with silver metal drawer pulls | |
| Hardware components | Ball-bearing steel drawer slides, dual-wheel nylon casters, steel adjustable levelers, central pedestal lock |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Integrated desk grommets and partition base raceways route power/data cables | |
|---|---|---|
| Pedestal mobility | Four dual-wheel casters on pedestal allow repositioning under desk, central lock secures all 3 drawers | |
| Floor leveling | Adjustable feet on desk legs and partition bases correct uneven floor surfaces | |
| Modular configuration | Reversible partition panels support left or right pedestal layout for open office planning |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff workstations | Provides individual privacy while supporting collaborative office layouts | |
|---|---|---|
| Call center and administrative work areas | Standard height partitions balance focus and supervisor visibility |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and performance requirements, applicable to work surface design | |
|---|---|---|
| EN 1335-1:2020 | Office furniture work chair dimensional requirements, reference for clearance ergonomics | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to mobile pedestal components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard, recommended for commercial procurement | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units safety and performance standard, applicable to mobile pedestal testing | |
| ANSI/BIFMA X7.1-2022 | Furniture emissions standard, low formaldehyde emission requirement for office furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and pedestal components | |
|---|---|---|
| GB/T 3325-2017 | Test methods for metal furniture hardware, applicable to slides and frame components | |
| GB 18584-2001 | Indoor decoration material limits of formaldehyde for wood furniture, emission limit requirement |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and pedestal components; 2. GB/T 3325-2017: Test methods for metal furniture hardware, applicable to slides and frame components; 3. GB 18584-2001: Indoor decoration material limits of formaldehyde for wood furniture, emission limit requirement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
