Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 1600 x 1600 x 1200 mm | |
|---|---|---|
| Standard work surface height | 750 mm | |
| Work surface depth (main segment) | 700 mm | |
| Work surface depth (return segment) | 600 mm | |
| Seated knee clearance height under worktop | 650 mm | |
| Knee well opening width | 800 mm | |
| Work surface thickness | 25 mm | |
| PVC edge band thickness | 2 mm | |
| Partition total height | 1200 mm | |
| Upper slatted translucent screen height | 300 mm | |
| Integrated storage cabinet width | 400 mm | |
| Storage cabinet depth | 550 mm | |
| Cable grommet diameter | 60 mm | |
| Open shelf compartment depth | 300 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Worktop uniform static load capacity | 80 kg | |
|---|---|---|
| Per-drawer/cabinet shelf dynamic load | 15 kg | |
| Drawer slide open/close cycle rating | 50000 cycles | |
| Adjustable leveling foot load rating | 120 kg per foot | |
| Surface abrasion resistance | 2000 revolutions | |
| Maximum recommended user weight for workstation | 120 kg | |
| Cabinet door hinge open/close cycle rating | 80000 cycles | |
| Product net weight reference | 95 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | 25mm thick E1-grade particleboard | |
|---|---|---|
| Storage cabinet and shelf panels | 18mm thick E1-grade melamine particleboard | |
| Privacy partition frame | 1.2mm thick powder-coated aluminum alloy | |
| Upper privacy screen section | Translucent frosted polycarbonate louver slats | |
| Lower partition solid panel | 16mm thick melamine particleboard | |
| Edge banding | 2mm thick impact-resistant PVC | |
| Drawer/cabinet slides | 3-section cold-rolled steel ball-bearing slides | |
| Cabinet lock | Zinc alloy keyed cam lock | |
| Cable management components | ABS plastic round desk grommet and PVC under-desk raceway | |
| Leveling feet | Nylon base with steel threaded stem | |
| Panel connectors | Zinc-plated steel cam lock fasteners | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Cable routing system | 60mm diameter desk grommet paired with under-worktop raceway | |
|---|---|---|
| Lockable lower storage cabinet | Keyed cam lock secures single-door compartment for confidential office materials | |
| Open multi-level shelving | Rear hutch and side open compartments provide accessible storage for documents and office supplies | |
| Seated privacy partition | 1200mm tall L-shaped screen blocks direct sightlines between adjacent workstations | |
| Leveling adjustment | Threaded nylon feet adjust by 15mm to stabilize desk on uneven commercial flooring | |
| Work surface layout | L-shaped corner configuration provides dual work zones for computer and document tasks | |
| Slatted upper screen ventilation | Louvered translucent upper panel allows air circulation while maintaining seated privacy | |
| Modular panel assembly | Knock-down construction allows reconfiguration or addition of adjacent workstation units | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff workstations | Suitable for general administrative, finance and clerical staff seated work use | |
|---|---|---|
| Small business cubicle setups | Modular design fits single-user corner placement in limited office floor space | |
| Coworking space dedicated desks | Integrated storage and privacy support individual assigned work areas | |
| Government and institutional office areas | Durable construction meets commercial procurement performance requirements | |
| Call center workstations | Partition height provides acoustic and visual separation between agents | |
| Back-office data processing areas | L-shaped worktop supports dual-monitor and document processing tasks |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable for safety and strength requirements for office work desks | |
|---|---|---|
| EN 1335-1:2020 | Applicable for ergonomic dimension compatibility with office task chairs | |
| EN 13722:2004 | Applicable for strength and durability requirements for office storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable for desk products: strength, durability and structural performance requirements | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable for storage units integrated into office workstation systems |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Applicable for formaldehyde emission limits for wood-based panel products (≤0.124mg/m³) | |
| GB/T 4897.3-2003 | Applicable for particleboard used in furniture structural applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture; 2. GB 18580-2017: Applicable for formaldehyde emission limits for wood-based panel products (≤0.124mg/m³); 3. GB/T 4897.3-2003: Applicable for particleboard used in furniture structural applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
