Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2820 x 1420 x 1100 mm | |
|---|---|---|
| Standard worksurface height | 750 mm | |
| Worksurface thickness | 25 mm | |
| Privacy partition thickness | 60 mm | |
| Per-workstation main work surface width | 1400 mm | |
| Per-workstation return surface depth | 700 mm | |
| Knee clearance height under worksurface | 680 mm | |
| Knee clearance opening width per station | 700 mm | |
| Mobile pedestal dimensions | 400 x 500 x 650 mm | |
| Upper slatted vented partition height | 320 mm | |
| Lower solid partition panel height | 780 mm | |
| Cable grommet diameter | 60 mm | |
| Caster wheel diameter | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Uniform worksurface static load capacity | 120 kg | |
|---|---|---|
| Mobile pedestal drawer static load per drawer | 30 kg | |
| Recommended maximum user weight per workstation | 110 kg | |
| Total workstation net weight | 160 kg | |
| Worksurface abrasion resistance rating | 2000 cycles | |
| Surface scratch resistance rating | 2H pencil hardness | |
| Partition frame static load for hanging accessories | 10 kg | |
| Structural warranty period | 5 years | |
| Available color finish options | 6 | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface core and finish | E1-grade melamine-faced particleboard, 25 mm thick, vertical light wood grain | |
|---|---|---|
| Worksurface edge treatment | 2 mm thick PVC edge banding, impact and water resistant | |
| Lower privacy partition panel | Fabric-wrapped MDF core, muted sage green matte finish | |
| Upper partition section | Slatted vented plastic/acoustic panel with aluminum retaining trim | |
| Partition support framing | Powder-coated aluminum extrusion, dark neutral finish, modular connection brackets | |
| Mobile pedestal body | 18 mm thick melamine-faced particleboard, matching light wood grain with sage green drawer front | |
| Mobile pedestal hardware | Black epoxy-coated steel drawer slides, recessed plastic/steel pull handle, 360-degree swivel casters | |
| Modesty panel under worksurface | 18 mm thick melamine-faced particleboard, matching light wood grain, fixed to desk frame | |
| Cable management components | ABS plastic cable grommet, concealed under-desk PVC cable raceway | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Per-station storage layout | One integrated rolling mobile pedestal per workstation, fits fully under desk top | |
|---|---|---|
| Mobile pedestal mobility | Four 360-degree swivel nylon casters, two with lock function, drawer holds A4 files | |
| Cable management system | Corner desk grommet routes power/data cables to under-desk raceway, hides wiring | |
| Privacy partition function | 1100 mm tall screens block seated line of sight, upper slats allow air circulation | |
| Modular reconfiguration | Aluminum frame connectors allow repositioning or expansion of the cubicle layout | |
| Foot adjustment | Threaded adjustable leveling feet on desk legs compensate for uneven office floors | |
| Partition accessory compatibility | Integrated aluminum slots support hanging file pockets, monitor arms and task lighting | |
| Assembly configuration | Flat-pack knock-down assembly with cam-lock and bolt fasteners for on-site build | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office space | Designed for 2 adjacent staff positions with seated privacy between users | |
|---|---|---|
| Small team work zones | Suitable for administrative, finance or customer service teams needing focused work space | |
| Startup and flexible office environments | Modular design supports later expansion to larger cubicle clusters | |
| Corporate staff work areas | Neutral sage and light wood finish coordinates with modern commercial office interiors | |
| Branch office deployments | Flat-pack packaging reduces freight cost for multi-site office furnishing projects | |
| Recommended pairing | Use with mid-back ergonomic office chairs, desktop monitor arms and under-desk CPU holders |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applies to worksurface and frame design | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional and mechanical performance requirements | |
| EN 1335-1:2020 | Office furniture seating dimensional coordination, applies to knee clearance sizing | |
| EN 1022:2018 | Furniture stability test methods for seating and storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applies to static load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applies to mobile pedestal testing | |
| ANSI/BIFMA X7.1-2020 | Formaldehyde emission standard for low-emitting office furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applies to desk surfaces and storage components | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks, applies to structural load and stability verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applies to E1-grade particleboard components | |
| GB/T 4897.3-2015 | Performance requirements for particleboard used in furniture, applies to desk core materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applies to desk surfaces and storage components; 2. GB/T 3327-2016: Performance test methods for office desks, applies to structural load and stability verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applies to E1-grade particleboard components; 4. GB/T 4897.3-2015: Performance requirements for particleboard used in furniture, applies to desk core materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
