Product supplierSingle-Person L-Shaped Cubicle Workstation Desk with Glass Partitions and Integrated Lockable Storage, E0 grade melamine-faced particle board
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 1600 × 1200 mm | |
|---|---|---|
| Overall station footprint | 1600 x 1600 x 1200 mm | |
| Work surface height from floor | 760 mm | |
| Work surface thickness | 25 mm | |
| Work surface depth (main straight sections) | 600 mm | |
| Knee well clear height under worktop | 680 mm | |
| Knee well clear width at front curved opening | 900 mm | |
| Partition panel total height | 1200 mm | |
| Partition frame wall thickness | 1.2 mm | |
| Partition panel thickness (wood lower section) | 32 mm | |
| Glass upper partition panel thickness | 5 mm | |
| Lower storage cabinet internal dimensions | 450 x 520 x 600 mm | |
| Cable grommet diameter | 60 mm | |
| Adjustable foot height adjustment range | 10 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Work surface static load capacity | 300 kg | |
|---|---|---|
| Product net weight | 95 kg | |
| Recommended maximum user weight for seated use | 120 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Surface scratch resistance rating | 2H | |
| Partition sound transmission class (STC) | 25 | |
| Edge banding peel strength | 1.5 N/mm | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface substrate | E0 grade melamine-faced particle board | |
|---|---|---|
| Storage cabinet and side panels | E1 grade melamine-faced particle board with white finish | |
| Partition frames | Powder-coated dark gray aluminum alloy | |
| Upper partition panels | 5mm frosted semi-transparent tempered glass | |
| Lower partition panels | 32mm thick melamine-faced wood composite panel | |
| Edge banding | 2mm thick PVC matching worktop and cabinet finish | |
| Drawer and cabinet pulls | Brushed silver aluminum alloy handles | |
| Drawer and cabinet lock | Zinc alloy keyed cam lock | |
| Support feet | Nylon-padded adjustable steel leveling feet | |
| Cable grommet | ABS plastic round cable port with brush insert | |
| Knee well modesty panel | 16mm thick dark gray melamine composite panel | |
| Modular connection hardware | Powder-coated steel connecting brackets |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seated work access | Curved front knee opening allows centered seated position at L-corner work zone | |
|---|---|---|
| Privacy screening | 1200mm tall partial-height partitions block seated sightlines between adjacent workstations | |
| Integrated lockable storage | Right-side pedestal includes 1 lockable top drawer for valuables and 1 lower door cabinet for files/CPU | |
| Cable management | Corner desk grommet routes monitor, power and data cables from desktop to floor, paired with lower partition wire channels | |
| Floor leveling | Adjustable nylon-padded feet at all support points compensate for uneven office flooring, eliminating desk wobble | |
| Modular expansion | Steel connecting brackets allow linking to additional matching workstation units to create multi-seat cubicle clusters | |
| Surface maintenance | Smooth melamine finish resists common office stains, allows wipe-clean maintenance with standard office cleaners | |
| Storage access | Full-extension drawer slide on top drawer provides complete access to stored stationery, cabinet door opens 110 degrees for unobstructed interior access | |
| Lockable top drawer internal dimensions | 450 x 380 x 120 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office staff workstations | Modular cubicle design provides individual privacy while supporting high-density seat layout for team offices | |
|---|---|---|
| Call center and administrative staff zones | 1200mm partition height reduces visual distraction while preserving supervisor line of sight for operational teams | |
| Small business and startup office spaces | Single L-station footprint fits compact floor plans, integrates storage to reduce need for separate cabinet furniture | |
| Government and corporate back-office areas | Durable melamine construction and lockable storage meet requirements for secure, high-traffic administrative work areas | |
| Hot-desking and hybrid work zones | Neutral light oak and white finish matches modern office decor, cable management supports flexible device setup for rotating users | |
| Modular office expansion projects | Connecting bracket design allows incremental addition of seats as team headcount grows, without full office reconfiguration |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements, applicable to work surface design | |
|---|---|---|
| EN 1022:2018 | Furniture seating and table stability test method, applicable to workstation stability | |
| EN 13986:2004 | Wood-based panels for construction and furniture use, applicable to panel substrate performance | |
| EN 12603:2001 | Office furniture storage units, performance requirements, applicable to integrated cabinet and drawer |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for office desks and work surfaces, applicable to worktop load and durability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Standard for office storage units, applicable to integrated drawer and cabinet performance | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable to material emissions and recyclability |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and cabinet construction | |
|---|---|---|
| GB/T 3327-2018 | Technical requirements for office desks and tables, applicable to work surface load and stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture use | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to desk strength and durability |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and cabinet construction; 2. GB/T 3327-2018: Technical requirements for office desks and tables, applicable to work surface load and stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture use; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to desk strength and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
