Automatic mm / inch conversion · Core engineering specifications
| Primary Component Thickness | 40 mm according to load-bearing role | |
|---|---|---|
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total net weight per workstation set | 320 kg | |
|---|---|---|
| Worksurface static point load capacity | 100 kg | |
| Seated user capacity | 3 | |
| Worksurface abrasion resistance (recommended) | 2000 cycles | |
| Partition panel tack holding capacity | 500 g per 100x100mm area | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface top | 25mm thick particleboard with matte grey laminate finish, 2mm PVC edge banding | |
|---|---|---|
| Lower partition section | 18mm thick MDF core with dark grey fabric upholstery tackable surface | |
| Upper partition section | Frosted semi-transparent acrylic glazing with silver-toned aluminum frame trim | |
| Support end panels | 25mm thick particleboard with dark grey melamine finish, fixed floor leveler glides | |
| Storage cabinet drawer fronts | 18mm thick particleboard with dark grey melamine finish, integrated recessed pull handles | |
| Storage cabinet door fronts | 18mm thick particleboard with light grey melamine finish, concealed euro-style hinges | |
| Partition connection hardware | 1.2mm thick cold-rolled steel with powder-coated silver finish, modular post connectors | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Modular partition system | Pre-fabricated panels connect via universal steel posts to reconfigure workstation cluster layout | |
|---|---|---|
| Integrated under-desk storage | Each work position has 1 lockable filing drawer and 1 lower storage cabinet door for personal item storage | |
| Semi-privacy screening | 1200mm tall partition height blocks seated line of sight between adjacent work positions to reduce distraction | |
| Curved corner worksurface | Seamless radiused corner creates extended work area for monitor placement and document handling across connected positions | |
| Cable management access | Recessed cable ports at partition base route power and data cables from floor outlets to desktop devices | |
| Adjustable floor leveling | Threaded glides at base of all support panels compensate for uneven floor surfaces to keep worksurface flat | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office departments | Creates defined individual work zones in open office layouts to reduce cross-staff visual distraction | |
|---|---|---|
| Administrative and clerical teams | Supports document processing, computer work and personal storage for daily administrative task execution | |
| Call center and back-office operations | Provides cost-effective semi-private workstations for high-density staff seating arrangements | |
| Temporary or long-term project teams | Modular construction allows reconfiguration as team size or project requirements change |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables - Safety and strength requirements for fixed-height office desks | |
|---|---|---|
| EN 1335-1:2020 | Office furniture - Office work chairs, applicable for clearance compatibility validation | |
| EN 1023-2:2000 | Office storage furniture - Safety and strength requirements for under-desk cabinets |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Standard for strength, durability and safety of office storage |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for worksurface and cabinet structural validation | |
|---|---|---|
| GB/T 35607-2017 | Limits of harmful substances in office furniture panels, applicable for formaldehyde emission verification | |
| GB 28007-2011 | Safety requirements for children's and institutional furniture, applicable for anti-tip and edge safety validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for worksurface and cabinet structural validation; 2. GB/T 35607-2017: Limits of harmful substances in office furniture panels, applicable for formaldehyde emission verification; 3. GB 28007-2011: Safety requirements for children's and institutional furniture, applicable for anti-tip and edge safety validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
