Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended user capacity | 1 person | |
|---|---|---|
| Work surface distributed load | 60 kg | |
| Static point load at center | 30 kg | |
| Privacy panel lateral stability load | 15 kg per panel | |
| Product net weight | 78 kg | |
| Recommended monitor configuration | 2 displays up to 27 in | |
| Floor leveling adjustment | 10 mm | |
| Durability target for moving hardware | 50,000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25 mm wood-grain high-pressure laminate board with matching sealed edge | |
|---|---|---|
| Side support panels | 25 mm light grey melamine-faced particleboard panels | |
| Upper privacy infill | Light grey fabric-covered panel over composite board | |
| Mid-height rear rail | Wood-grain laminate infill matching the desktop | |
| Lower modesty panels | Warm grey composite panels with black horizontal trim rails | |
| Vertical structural posts | Black powder-coated steel square posts at panel intersections | |
| Panel edge frame | Black PVC or aluminum trim with dark grey end posts | |
| Cable grommet | 60 mm brushed silver metal or ABS rim with black opening | |
| Leveling feet | Black nylon-padded screw feet with steel threaded stems | |
| Corner connectors | Steel bracket-and-post connectors joining desktop, screens and modesty panels | |
| Substrate recommendation | E1-grade particleboard or MDF, 25 mm desktop and 18 mm infill panels | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| L-shaped work layout | Two 1400 mm returns create a corner task surface for computing, writing and document placement | |
|---|---|---|
| Visual privacy screening | Two 450 mm-high screens above the desktop form a rear corner barrier between adjacent users | |
| Cable routing | One 60 mm rear-corner grommet allows monitor and power cables to pass below the work surface | |
| Under-desk concealment | Rear modesty panels hide cables and the user's leg area while leaving the curved front open for entry | |
| Floor leveling | Threaded rear leveling feet compensate for uneven carpet or tile by up to 10 mm | |
| Panel system expansion | Vertical end posts allow additional desks or divider panels to connect in bench or cluster runs | |
| Fixed seated-height design | The desk is supported at 750 mm and has no electric or manual height-adjustment mechanism | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office | Provides one defined seated workstation with rear privacy panels in dense bench-style office layouts | |
|---|---|---|
| Administrative workstation | Suitable for clerks, coordinators and operators using two monitors, a keyboard and paperwork | |
| Call-center row installation | End posts and uniform panel thickness allow repeated units to be linked into rows or clusters | |
| Shared service office | Works in government halls, reception back offices and customer-support centers requiring visual separation | |
| Small private office | Fits one user in a compact room where a compact L-shape provides computing and writing zones | |
| Project-based staffing | Suitable for temporary or expanding teams when multiple identical flat-packed stations are deployed |
EU Market Access Requirements* EN Standards
| Office furniture safety and stability | EN 16139 covers strength, durability and safety requirements for non-domestic seating-area furniture and work furniture | |
|---|---|---|
| Work surface dimensions | EN 527specifies dimensions and safety requirements for office desks and work tables | |
| Mechanical test methods | EN 527provides mechanical safety and structural test methods for office desks | |
| Office storage panel safety | EN 14073 applies where linked storage or pedestal components are added | |
| Indoor air emissions | EN 16516 supports VOC and formaldehyde emission assessment of construction products |
US and Canada office-furniture standards
| Desk strength and durability | ANSI/BIFMA X5.5 provides load, fatigue and stability tests for desk products | |
|---|---|---|
| Panel screen attachment | ANSI/BIFMA X5.5 Section 11 through 13-style edge and vertical-load tests can validate screen connections | |
| Formaldehyde certification | ANSI/BIFMA e3 sustainability credit 7.6.1 addresses low-emitting furniture and panel components |
Standards applicable to China-market projects
| Dimensional and structural acceptance | GB/T 3324 applies general technical requirements for wooden furniture dimensions, stability and workmanship | |
|---|---|---|
| Laminate desktop surface testing | GB/T 4893 covers furniture surface resistance to wear, heat, pollution and impact | |
| Formaldehyde control | GB 18580 sets formaldehyde emission limits for wood-based panels used indoors | |
| Safety and stability | GB/T 10357 provides furniture strength, durability and stability test methods |
This product must meet the following technical requirements: 1. Dimensional and structural acceptance: GB/T 3324 applies general technical requirements for wooden furniture dimensions, stability and workmanship; 2. Laminate desktop surface testing: GB/T 4893 covers furniture surface resistance to wear, heat, pollution and impact; 3. Formaldehyde control: GB 18580 sets formaldehyde emission limits for wood-based panels used indoors; 4. Safety and stability: GB/T 10357 provides furniture strength, durability and stability test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
