Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (L x W x H) | 1500 x 1400 x 1100 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Work surface thickness | 25 mm | |
| Work surface depth (primary work area) | 600 mm | |
| Return work surface depth (side work area) | 500 mm | |
| Privacy screen total height | 350 mm | |
| Knee clearance height under work surface | 650 mm | |
| Knee clearance width (central open area) | 800 mm | |
| Knee clearance depth under work surface | 450 mm | |
| Integrated storage pedestal width | 400 mm | |
| Storage pedestal depth | 500 mm | |
| Storage drawer internal height | 120 mm | |
| Lower storage cabinet internal height | 450 mm | |
| Cable grommet diameter | 60 mm | |
| Metal leg section diameter | 30 mm | |
| Edge banding thickness | 2 mm |
Net weight / load capacity / users / durability
| Static uniform load capacity (work surface) | 91 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Unit net weight | 68 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Static load per metal leg | 40 kg | |
| Recommended seated user weight capacity | 136 kg | |
| Finish stain/water resistance rating | Level 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | 18mm E0-grade particleboard | |
|---|---|---|
| Work surface finish | Light oak effect thermally fused melamine laminate | |
| Drawer front accent panel | 15mm MDF with matte sage green powder coating | |
| Lower cabinet door panel | 18mm particleboard with vertical fluted light oak melamine finish | |
| Privacy screen frame | 20x20mm dark powder-coated square steel tubing | |
| Upper privacy screen section | Perforated decorative slatted panel with light finish | |
| Lower privacy screen modesty panel | 12mm particleboard with sage green melamine finish | |
| Support legs | Dark powder-coated tapered steel tubing with adjustable foot glides | |
| Cable management grommets | ABS plastic with brushed silver finish cap | |
| Drawer handle | Black ABS plastic with oval recessed design | |
| Desk side modesty panels | 12mm particleboard with light oak melamine finish | |
| Edge banding | 2mm PVC edge banding matching light oak finish |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Two 60mm desktop grommets route power and data cables to floor | |
|---|---|---|
| Storage configuration | Left fixed pedestal with open upper shelf, 1 supply drawer, 1 lower cabinet | |
| Drawer operation | Side-mounted ball-bearing slides enable full extension and soft close | |
| Privacy separation | Two-sided corner screen blocks direct line of sight from adjacent work areas | |
| Floor adjustment | Adjustable foot glides on each leg compensate for uneven office floors | |
| Assembly configuration | Knock-down flat-pack assembly with cam-lock and screw fasteners | |
| Work surface layout | 90-degree L-shaped corner design provides two adjacent work zones | |
| Modesty protection | Solid side and lower screen panels block leg visibility from aisle areas | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office individual workstations | Provides privacy and dedicated storage for staff in shared office environments | |
|---|---|---|
| Small business private offices | Compact L-shaped footprint fits small rooms while offering adequate work surface | |
| Home office dedicated workspaces | Combines work area, storage and visual separation for remote work setups | |
| Call center cubicle deployments | Standard single-seat footprint fits high-density call center floor plans | |
| Co-working space dedicated desks | Fixed assigned desk option with built-in privacy for co-working members | |
| Startup office open floor plans | Quick-deploy knock-down design supports fast office layout reconfiguration |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural load verification | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional and safety requirements, applicable to ergonomic clearance checks | |
| EN 14372:2004 | Office furniture hardware performance requirements, applicable to drawer slide and fastener testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to static load and cycle testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer and cabinet load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel strength and finish quality | |
|---|---|---|
| GB/T 3327-2018 | Performance requirements for office desks, applicable to work surface load and stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E0-grade substrate verification | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture use, applicable to worktop and panel substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel strength and finish quality; 2. GB/T 3327-2018: Performance requirements for office desks, applicable to work surface load and stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E0-grade substrate verification; 4. GB/T 4897.3-2003: Particleboard specifications for furniture use, applicable to worktop and panel substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
