Product supplierSingle-Person L-Shaped Office Cubicle Workstation Desk with Dividers and Storage, 25mm thick melamine-faced MFC board, PVC edge banding
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 1200 × 1200 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 40 kg | |
|---|---|---|
| Static worktop uniform load capacity | 100 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Surface stain and water resistance | Level 5 | |
| Recommended maximum seated user weight | 110 kg | |
| Commercial product warranty | 5 years | |
| Available finish color options | 60 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop surface | 25mm thick melamine-faced MFC board, PVC edge banding | |
|---|---|---|
| Storage cabinet panels | 18mm thick melamine-faced engineered wood, white and light oak finish | |
| Privacy divider frame | White powder-coated rectangular steel tubing | |
| Privacy divider infill panels | Beige fabric over fiberboard core, sound-dampening | |
| Support legs | Black powder-coated tapered steel legs, floor protection glides | |
| Drawer slides | Cold-rolled steel 3-section silent ball-bearing slides | |
| Drawer lock | Zinc alloy cam lock with 2 keys | |
| Cable grommets | ABS plastic round desk grommets with brush insert | |
| Frame finish coating | Epoxy polyester powder coat, scratch-resistant | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Privacy partition design | 3-sided low dividers separating adjacent workstations, seated eye-level screening | |
|---|---|---|
| Storage configuration | Under-main-top pedestal with 1 lockable upper drawer and 1 lower door cabinet, plus side return full-height cabinet | |
| Cable management | 2 worktop cable grommets routing power/data cords from surface to under-desk area | |
| Modular assembly | Knock-down flat-pack construction allowing connection to adjacent workstations for cluster layouts | |
| Drawer operation | Full-extension ball-bearing slides allowing 100% drawer access, soft-close damping | |
| Storage compartment access | Hinged lower cabinet door with magnetic catch, open access without protruding handles | |
| Floor leveling | Adjustable glides on support legs compensating for 10mm of uneven floor height | |
| Customization compatibility | Pre-drilled mounting points for optional keyboard trays, CPU holders, and monitor arms | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office work areas | Individual seated work zone for general administrative and clerical staff, with visual privacy from dividers | |
|---|---|---|
| Small business and startup offices | Modular design allowing cluster arrangement to fit compact open floor plans without major construction | |
| Shared coworking spaces | Defined individual workstations separated by dividers to reduce cross-user distraction | |
| Call center and customer service floors | High-density cubicle layouts with integrated storage for personal work materials | |
| Government and corporate back-office areas | Durable commercial-grade construction suited for 8-hour daily long-term use | |
| Home office dedicated work zones | Compact L-shaped layout providing separate work and storage surfaces for telecommuting use |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables - Part 1: Dimensions, applicable to work surface height and clearance verification | |
|---|---|---|
| EN 527-2:2016 | Office worktables - Part 2: Mechanical safety requirements, applicable to stability and load testing | |
| EN 1335-1:2020 | Office furniture - Office work chairs, applicable to compatibility with seated workstation dimensions |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and cabinet panel quality | |
|---|---|---|
| GB/T 3327-2016 | Office desk performance test methods, applicable to load and stability verification | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture, applicable to formaldehyde emission checks | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to strength and durability validation |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and cabinet panel quality; 2. GB/T 3327-2016: Office desk performance test methods, applicable to load and stability verification; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture, applicable to formaldehyde emission checks; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to strength and durability validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
