Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 78 kg | |
|---|---|---|
| Worktop distributed load | 60 kg | |
| Lower shelf equipment load | 25 kg | |
| Recommended occupancy | 1 receptionist | |
| Panel screw pull-out resistance | 80 kgf | |
| Leveling adjustment | 15 mm | |
| Suggested daily user capacity | 120 visitors | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main worktop | 25 mm wood-composite core with warm woodgrain melamine face and sealed edge banding | |
|---|---|---|
| Front and side panels | 18 mm light-gray melamine-faced composite panels with dark edge trim | |
| Right tower exterior | Light-gray melamine panel with rounded front corner and matching laminated interior | |
| Upper screen frame | Dark-gray powder-coated metal or aluminum rectangular frame | |
| Slatted screen infill | Horizontal light-gray aluminum-look slats with 12 visible ventilation-style openings | |
| Back modesty panel | Full-height light-gray composite panel with dark horizontal dividing rail | |
| Internal shelf board | 18 mm gray melamine-faced composite shelf with circular cable opening | |
| Edge protection | 2 mm PVC edge banding on high-impact exposed edges | |
| Leveling feet | Injection-molded polymer circular glides with threaded metal stems | |
| Fastening hardware | Cam locks, confirmat screws, and corner connector brackets for flat-pack assembly | |
| Cable grommet | White polymer oval desk grommet and gray circular shelf grommet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Visitor privacy barrier | Front modesty panel and 320 mm raised screen shield paperwork and seated leg space | |
|---|---|---|
| Desktop cable routing | Oval grommet routes monitor and power cables from the worktop into the rear service zone | |
| Tower equipment compartment | Right-side open 350 mm high bay accepts a computer host or printer with shelf-level cable exit | |
| Upper side storage shelf | Raised side shelf provides a secondary transaction surface or forms/documents storage | |
| Floor leveling | Threaded circular feet adjust up to 15 mm to stabilize the cabinet and main desk independently | |
| Modular panel assembly | Main desk, front barrier, screen frame, and right tower join through panel connectors for site assembly | |
| Rear service access | Open right-tower interior allows cable and equipment access without moving the complete reception desk | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Main carton dimensions | 1850 x 680 x 120 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office entrance | Suitable for one receptionist handling visitor registration, access control, and phone inquiries | |
|---|---|---|
| Medical or clinic lobby | Front barrier supports privacy while the right shelf holds a computer host or document tray | |
| Hotel or apartment concierge | Compact 1800 mm width fits small lobbies requiring a professional transaction counter | |
| Education or training center | Provides sign-in, badge issuance, and visitor direction at the entry area | |
| Government service hall | Solid modesty panel and cable management support a clean public-facing workstation | |
| Small showroom reception | Neutral gray and woodgrain finish coordinates with modern lounge and display furniture | |
| Recommended companion equipment | Pair with one ergonomic task chair, monitor arm, transaction tray, and under-desk CPU holder |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office desk safety, strength, and durability requirements, applicable to the seated work surface | |
|---|---|---|
| EN 15372:2016 | Safety, strength, and durability requirements for non-domestic storage furniture, applicable to the right tower | |
| EN 14073-2:2004 | Safety requirements for office storage furniture, applicable to shelf and cabinet panel performance | |
| EN 717-1:2004 | Wood-based panel formaldehyde emission classification, suitable as panel emission acceptance reference |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard, applicable to worktop strength and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units safety and performance standard, applicable to the integrated shelf tower | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, usable only if supplier declares material and emission credits |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel dimensions, edge quality, and workmanship | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable if the screen frame is metal | |
| GB/T 10357.5-2011 | Furniture surface physical and chemical test method for wear resistance, suitable for melamine worktop acceptance | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, recommended for panel procurement documentation | |
| GB/T 10357.1-2013 | Table mechanical test method for strength and stability, suitable for reception-desk acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel dimensions, edge quality, and workmanship; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable if the screen frame is metal; 3. GB/T 10357.5-2011: Furniture surface physical and chemical test method for wear resistance, suitable for melamine worktop acceptance; 4. GB 18580-2017: Formaldehyde emission limit for wood-based panels, recommended for panel procurement documentation; 5. GB/T 10357.1-2013: Table mechanical test method for strength and stability, suitable for reception-desk acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
