Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2800 x 2800 x 1200 mm | |
|---|---|---|
| Per-seat work surface | 1200 x 600 x 25 mm | |
| Work surface height | 750 mm | |
| Privacy partition height | 1200 mm | |
| Partition panel thickness | 60 mm | |
| Cable grommet diameter | 50 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance depth | 550 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Frosted upper panel height | 300 mm | |
| Frame extrusion width | 30 mm | |
| Leveler adjustment range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Per-seat static worktop load | 100 kg | |
|---|---|---|
| Total workstation net weight | 260 kg | |
| Mobile pedestal drawer static load | 30 kg | |
| Worksurface abrasion resistance | 2000 cycles | |
| Recommended user capacity | 4 people | |
| Partition frame connection load | 80 kg | |
| Leveler load capacity per foot | 50 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm E1 grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Partition frame | 1.2mm thick powder-coated silver aluminum alloy extrusion | |
| Lower partition infill | Fabric-wrapped 18mm MDF panel with muted sage finish | |
| Upper partition infill | 5mm frosted semi-transparent acrylic panel | |
| Modesty panel | 18mm melamine-faced light gray particleboard | |
| Mobile pedestal body | 0.8mm thick cold-rolled steel with off-white powder coat | |
| Cable grommet | ABS plastic with black brush insert | |
| Leveler feet | Nylon base with steel threaded stud | |
| Mobile pedestal casters | 50mm diameter hard nylon swivel casters | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Desktop grommets route power/data cables to under-desk raceways | |
|---|---|---|
| Floor leveling | Threaded adjustable feet at all frame bases correct uneven floor surfaces | |
| Mobile pedestal storage | Each cabinet includes 1 lockable top drawer and 1 lower filing compartment | |
| Privacy separation | 1200mm tall partitions block direct line of sight between adjacent seated users | |
| Light transmission | Upper frosted panels allow overhead light to pass between workstations | |
| Modular assembly | Knock-down frame connections support future reconfiguration of layout | |
| Caster mobility | Mobile pedestals roll freely for under-desk storage or repositioning | |
| Edge protection | PVC edge banding prevents chipping and moisture damage to worktop edges | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office areas | Provides separated individual workspaces for teams in shared office floors | |
|---|---|---|
| Startup and small business offices | Compact footprint maximizes seat count without dedicated private offices | |
| Call center and administrative workspaces | Partial dividers reduce distraction while maintaining supervisor visibility | |
| Temporary office fit-outs | Modular knock-down design supports fast deployment and future reconfiguration | |
| Administrative staff work areas | Integrated pedestal storage supports document and office supply organization | |
| Office renovation projects | Standard dimensions align with typical raised floor and ceiling office layouts |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to work surfaces | |
|---|---|---|
| EN 1335-1:2020 | Office furniture reference for ergonomic desk height and clearance dimensions | |
| EN 1022:2018 | Domestic and contract furniture stability test method, applicable to workstation stability |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and panel components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel pedestals and frame | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office use | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to worktop load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and panel components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel pedestals and frame; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office use; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to worktop load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
