Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 1400 x 1400 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Work surface thickness | 25 mm | |
| Work surface depth (per wing) | 600 mm | |
| Knee well clearance height | 680 mm | |
| Knee well minimum width | 700 mm | |
| Partition panel thickness | 83 mm | |
| Upper frosted divider height | 300 mm | |
| Lower fabric panel height | 900 mm | |
| Storage cabinet overall dimensions | 400 x 600 x 700 mm | |
| Drawer internal dimensions | 350 x 520 x 120 mm | |
| Cable grommet diameter | 80 mm | |
| Edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 100000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Unit net weight (per seat) | 120 kg | |
| Recommended user capacity | 1 person per corner cubicle | |
| Partition acoustic noise reduction | 18 dB | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface core | E1 grade particleboard core | |
|---|---|---|
| Work surface finish | 0.6mm thick melamine laminate | |
| Edge banding | 2mm thick ABS edge strip | |
| Partition frame | 1.2mm thick powder-coated aluminum extrusion | |
| Lower partition panel | 16mm thick MDF core wrapped in polyester fabric | |
| Upper partition panel | 5mm thick frosted semi-transparent acrylic | |
| Storage cabinet body | 18mm thick melamine-faced MDF | |
| Hardware components | Zinc-plated steel locks, hinges and slides | |
| Base leveling glides | Nylon adjustable glides with steel inserts | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Lockable storage pedestal | 1 top lockable drawer + 1 lower lockable door cabinet | |
|---|---|---|
| Cable management system | Desktop cable grommet + under-desk wire raceway | |
| Modular partition connection | Aluminum profile quick-connect brackets | |
| Adjustable leveling feet | 15mm height adjustment range on all base supports | |
| Partial height privacy dividers | 1200mm total partition height | |
| Full-extension drawer access | 100% drawer extension on steel ball bearing slides | |
| Tackable fabric partition surface | Fabric-wrapped lower panels accept push pins | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff work areas | Modular design supports flexible open office layout configuration | |
|---|---|---|
| Small business team workspaces | Compact L-shape fits corner positions to maximize limited floor space | |
| Call center and administrative offices | Partial height dividers balance privacy and team communication access | |
| Co-working facility dedicated desks | Lockable storage secures personal items for assigned hot-desk users | |
| Government and corporate back offices | Commercial grade construction withstands high daily traffic use | |
| Branch office standard workstations | Consistent specification enables standardized multi-location deployment |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements | |
|---|---|---|
| EN 1335-1:2020 | Office furniture workstation dimensions | |
| EN 14073-2:2004 | Office storage furniture safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance and safety standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2019 | Office desk performance test methods | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2015 | Particleboard for furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2019: Office desk performance test methods; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 4897.3-2015: Particleboard for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
