| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 100 kg | |
|---|---|---|
| Partition panel lateral impact resistance | 200 N | |
| Total workstation net weight | 210 kg | |
| Designated user capacity | 2 people | |
| Adjustable foot maximum leveling load | 600 kg per leg | |
| Standard warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | 25 mm thick melamine-faced particleboard | |
|---|---|---|
| Partition frame | 1.2 mm thick powder-coated steel tubing | |
| Upper privacy panels | 3 mm thick frosted translucent acrylic | |
| Lower partition panels | 18 mm thick melamine-faced particleboard | |
| Modesty panel | 18 mm thick dark grey melamine-faced particleboard | |
| Mobile pedestal body | 0.8 mm thick cold-rolled steel with powder-coated off-white finish | |
| Pedestal casters | 50 mm diameter hard nylon swivel casters | |
| Leveling feet | Injection-molded nylon base with steel threaded stem | |
| Hardware components | Zinc-plated steel screws, cam locks and connecting brackets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management grommet | One 60 mm diameter circular cutout per work position at corner junction, routes power and data cables from desk surface to under-desk space | |
|---|---|---|
| Mobile pedestal storage | One lockable shallow top drawer for office supplies, one lower hinged door compartment for personal items, rolls freely on four casters to fit fully under desk | |
| Privacy partition system | Frame-supported two-tone panels with upper acrylic sections, creates visual separation between adjacent workstations while allowing overhead light transmission | |
| Floor leveling system | Threaded adjustable feet at all frame base points, rotated to compensate for uneven flooring and eliminate workstation wobble | |
| Modular expandability | Pre-drilled connecting points on steel frame edges, allows addition of extra workstations or reconfiguration of layout without custom modification | |
| Knock-down assembly | Flat-packed component set with included assembly hardware, allows on-site assembly without specialized welding or fabrication tools | |
| Storage compartment locking | Keyed lock on mobile pedestal top drawer, secures drawer and lower door compartment to prevent unauthorized access to stored items | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office spaces | Provides defined private work zones for staff in open office layouts without full wall construction | |
|---|---|---|
| Small to medium business work areas | Cost-effective two-person configuration suitable for team expansion with reconfigurable layout capability | |
| Administrative and clerical work positions | Ergonomic 750mm desk height and ample work surface depth suit daily computer, paperwork and administrative tasks | |
| Call center and shared office environments | Partition height balances privacy for focused work and visibility for team communication | |
| Temporary or relocatable office setups | Knock-down assembly and modular connections allow disassembly and relocation during office moves or layout changes | |
| Office layouts requiring integrated storage | Included mobile pedestals provide lockable personal storage without requiring separate free-standing cabinetry |
EU Market Access Requirements* EN Standards
| Office desk load requirement | EN 527:2002 Office furniture - Work tables and desks - Safety requirements | |
|---|---|---|
| Panel material emission standard | EN 13986:2004 Wood-based panels for use in construction - Characteristics, evaluation of conformity and marking | |
| Metal furniture durability | EN 15372:2016 Furniture - Strength, durability and safety - Requirements for non-domestic storage furniture | |
| Furniture surface abrasion resistance | EN 15185:2011 Furniture - Assessment of surface resistance to abrasion |
US and Canada office-furniture standards
| Desk load test standard | ANSI/BIFMA X2021Desk Products - Tests for stability, strength and durability | |
|---|---|---|
| Mobile storage unit standard | ANSI/BIFMA X2019Storage Units - Tests for safety, durability and structural performance |
Standards applicable to China-market projects
| Work surface dimensional tolerance | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Steel frame coating adhesion | GB/T 1993Determination of impact resistance of paint films | |
| Formaldehyde emission limit | GB 18580Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels | |
| Hardware corrosion resistance | GB/T 10125Corrosion tests in artificial atmospheres - Salt spray tests | |
| Office furniture stability | GB/T 10357.1Test of mechanical properties of furniture - Strength and durability of tables |
This product must meet the following technical requirements: 1. Work surface dimensional tolerance: GB/T 3324General technical requirements for wooden furniture; 2. Steel frame coating adhesion: GB/T 1993Determination of impact resistance of paint films; 3. Formaldehyde emission limit: GB 18580Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels; 4. Hardware corrosion resistance: GB/T 10125Corrosion tests in artificial atmospheres - Salt spray tests; 5. Office furniture stability: GB/T 10357.1Test of mechanical properties of furniture - Strength and durability of tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
