Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2800 x 2800 x 1200 mm | |
|---|---|---|
| Single L-shaped work surface per seat | 1400 x 1200 mm | |
| Work surface height above floor | 750 mm | |
| Total partition height from floor | 1200 mm | |
| Solid lower partition height | 750 mm | |
| Translucent upper partition height | 450 mm | |
| Work surface panel thickness | 25 mm | |
| Storage cabinet/drawer panel thickness | 17 mm | |
| Knee clearance height under desk | 620 mm | |
| Partition panel total thickness | 32 mm | |
| Per-seat drawer unit width | 400 mm | |
| Aluminum partition frame wall thickness | 1.2 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Single work surface static load capacity | 150 kg | |
|---|---|---|
| Overall product net weight | 280 kg | |
| Recommended maximum user weight per seat | 120 kg | |
| Surface wear resistance rating | 2000 cycles | |
| Panel static bending strength | 45 MPa | |
| Formaldehyde emission level | 0.015 mg/m³ | |
| Edge bond strength | 1.5 MPa | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm E1 grade melamine-faced particleboard, scratch/heat/water resistant | |
|---|---|---|
| Lower partition panels | 17mm dark grey melamine-faced particleboard, solid modesty panel | |
| Upper partition inserts | Frosted ribbed translucent acrylic/glass panel, horizontal striped texture | |
| Partition frame | 30-series anodized aluminum profile, powder coated dark bronze finish | |
| Edge banding | 1.5mm thick PVC edge banding, matching surface color | |
| Storage drawer/cabinet fronts | 17mm light grey melamine-faced particleboard, recessed integrated handles | |
| Cabinet carcass and modesty panels | 17mm dark grey melamine-faced particleboard, structural support | |
| Drawer slides | Cold-rolled steel full-extension ball bearing slides, zinc plated | |
| Adjustable foot glides | Nylon base with steel threaded stem, 10mm height adjustment | |
| Cable grommets | ABS plastic round cable ports, 60mm diameter, positioned at desk inner corner | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Seated privacy screen | 1200mm total height cross partition blocks direct line of sight between adjacent users | |
|---|---|---|
| Per-seat integrated storage | 1 pull-out drawer + 1 hinged door cabinet per position for personal/file storage | |
| Cable management access | Recessed cable grommets at inner work corner route power/data wires under desk | |
| Curved knee cutout | Concave rounded front desk edge creates ergonomic seated leg clearance at each position | |
| Floor leveling adjustment | Threaded nylon glides at cabinet base allow 10mm height adjustment for uneven floors | |
| Modular assembly | Knock-down panel connection allows reconfiguration of layout or replacement of individual panels | |
| Surface maintenance | Smooth melamine surface can be wiped clean with standard office cleaning agents, no sealing required | |
| Storage lock compatibility | Drawer and cabinet doors pre-drilled to accept optional cam locks for personal security | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office areas | Creates 4 individual semi-private workstations without full wall construction, suitable for 4 staff members | |
|---|---|---|
| Small business team work zones | Integrated storage removes need for separate filing cabinets, saves floor space in compact offices | |
| Call center and administrative departments | Partition height balances visual privacy and team communication for daily task work | |
| Startup and co-working spaces | Modular design supports easy reconfiguration as team size or layout needs change | |
| Government and enterprise staff offices | Meets standard commercial furniture durability and emission requirements for long-term daily use | |
| Recruitment and student service offices | Per-seat storage allows staff to keep documents and personal items organized at their workstation |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements for commercial work surfaces | |
|---|---|---|
| EN 14073-2:2004 | Storage furniture safety requirements for office drawers and cabinets | |
| EN 13722:2004 | Performance requirements for office workstation partitions and screens |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for load, durability and stability testing of work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer operation and load capacity testing | |
| ANSI/BIFMA X7.1-2020 | Formaldehyde emission standard for low-emitting office furniture components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to panel construction and dimensional tolerances | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, requires E1 grade for indoor office use | |
| GB/T 4897.3-2015 | Requirements for particleboard used in furniture construction, applicable to desk and cabinet panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to panel construction and dimensional tolerances; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, requires E1 grade for indoor office use; 3. GB/T 4897.3-2015: Requirements for particleboard used in furniture construction, applicable to desk and cabinet panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
