PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2830 × 2830 × 1100 mm
Overall footprint	2830 x 2830 x 1100 mm
Work surface height	750 mm
Per-user work surface size	1400 x 600 mm
Privacy partition total height	1200 mm
Partition panel thickness	30 mm
Worktop thickness	25 mm
PVC edge banding thickness	2 mm
Integrated drawer pedestal dimensions	400 x 400 x 600 mm
Under-desk knee clearance height	650 mm
Under-desk knee clearance depth	450 mm
Steel frame wall thickness	1.5 mm
Cable grommet diameter	60 mm
Support foot height	50 mm
Modesty panel height	400 mm
Open storage cubby height above drawer	120 mm
Finished Top Thickness	50 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total set net weight	350 kg
Worktop static uniform load capacity	100 kg
Drawer slide cycle rating	50000 cycles
Formaldehyde emission level	0.05 mg/m³
Partition acoustic noise reduction coefficient	0.8
Recommended user capacity	4 people
Laminate surface abrasion resistance	2000 cycles
Frame salt spray corrosion resistance	48 hours
Standard product warranty	5 years
Top Static Load Reference	150 kg uniformly distributed

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	E0 grade melamine laminated particleboard, light oak woodgrain finish
Drawer front accent panels	Melamine laminated board, sage green matte finish
Pedestal cabinet bodies	Light oak melamine laminated particleboard with vertical grain
Privacy partition panels	Fabric-covered composite core with dark metal trim, sage green fabric
Structural support frame	1.5mm thick cold-rolled steel with dark powder coating
Worktop edge banding	2mm thick impact-resistant PVC matching worktop finish
Support feet	Matte black tapered ABS plastic with anti-slip pad
Drawer locks	Zinc alloy keyed cam lock, one key per drawer
Partition top accent slats	Horizontal white louvered ABS trim on upper partition frames
Hardware fasteners	Zinc-plated steel connecting brackets for modular assembly
Modesty panels	Matching light oak melamine laminated particleboard
Drawer slides	Cold-rolled steel 3-section full extension ball bearing slides

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Lockable drawer storage	Keyed cam lock secures one lower drawer per station for personal item storage
Open cubby storage	120mm high open shelf above each lockable drawer for frequently accessed items
Cable management system	60mm diameter desk grommets per station and internal partition routing for power/data cables
Visual privacy screening	1200mm high fabric partitions block direct line of sight between adjacent seated users
Modular layout expansion	Steel connection brackets allow adding matching modules to extend workstation clusters
Floor level adjustment	Tapered support feet include adjustable glides to compensate for uneven floor surfaces
Acoustic privacy	Fabric partition surfaces absorb ambient office noise to reduce cross-seat distraction
Cable segregation	Separate internal routing channels separate low-voltage data and high-voltage power cables
Modesty screening	400mm high under-desk panels block visibility of seated users' legs between stations
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open plan office spaces	Suitable for high-density team seating while maintaining individual visual privacy
Small and medium business offices	Cost-effective cluster solution for 4-person teams in administrative departments
Call center and shared workspace environments	Partitioned layout reduces distraction for focused individual work
Corporate staff work areas	Integrated storage reduces need for separate pedestals, saving floor space
Startup and co-working locations	Modular design allows reconfiguration as team sizes change
Government and institutional offices	Durable commercial-grade construction supports high-frequency daily use

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office worktables safety and strength requirements, applicable to worktop and frame performance
EN 1335-1:2020	Office furniture workstation dimensions for seated use, applicable to clearance specifications
EN 12521:2015	Furniture strength durability and safety for commercial non-domestic tables

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk products standard for safety, durability and structural performance
ANSI/BIFMA X7.1-2022	Formaldehyde and TVOC emission standard for office furniture
ANSI/BIFMA G1-2013	Ergonomic guideline for office work surface dimensions and clearance

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirement for wooden furniture, applicable to desk panel and cabinet components
GB 18580-2017	Formaldehyde emission limit for wood-based panels, applicable to all laminated board components
GB/T 3325-2017	Metal furniture general technical requirements, applicable to steel frame and hardware components
GB/T 4897.3-2003	Particleboard for furniture use, applicable to worktop and cabinet substrate material

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirement for wooden furniture, applicable to desk panel and cabinet components;
2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to all laminated board components;
3. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and hardware components;
4. GB/T 4897.3-2003: Particleboard for furniture use, applicable to worktop and cabinet substrate material;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-CR4-2830-OAK-SG

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-CR4-2830-OAK-SG

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-CR4-2830-OAK-SGOpen Export Tool

Quick Actions

Post an RFQ

Product Description

This 4-person cross modular partitioned office workstation delivers a balanced, space-efficient seating solution for collaborative and focused work settings, arranged in a symmetrical cross layout that divides a 2830 x 2830 mm footprint into four equal, individually dedicated work zones. Each user station features a 1400 x 600 mm work surface set at a standard 750 mm height, framed by 1200 mm tall, 30 mm thick privacy partitions that block direct line of sight between seated adjacent users. The light oak woodgrain work surfaces are complemented by sage green matte drawer accents and matching sage green fabric partition panels, finished with dark metal trim, horizontal white louvered ABS top slats, and color-matched 2 mm thick impact-resistant PVC edge banding for a polished, coordinated aesthetic. The workstation is built on a 1.5 mm thick dark powder-coated cold-rolled steel frame, tapered matte black ABS support feet with anti-slip pads, and E0 grade melamine laminated particleboard for work surfaces and pedestal bodies. Each station includes an integrated lockable storage pedestal with a zinc alloy keyed cam lock securing one lower drawer for personal items, paired with a 120 mm high open cubby above for frequently accessed materials. Functional details include 60 mm desk grommets and internal partition cable routing to organize power and data cords, adjustable glides on support feet to level the unit on uneven floors, and fabric partition surfaces that absorb ambient office noise to reduce cross-seat distraction. Steel connection brackets support seamless addition of matching modules to expand workstation clusters as team needs evolve, with commercial-grade durability including a 100 kg worktop static load capacity, 50000-cycle drawer slide rating, 2000-cycle laminate abrasion resistance, and 0.05 mg/m³ formaldehyde emission level. This configuration is ideally suited for open plan offices, small and medium business administrative teams, call centers, shared workspaces, corporate staff areas, startup co-working locations, and government institutional offices, delivering integrated storage that eliminates the need for separate rolling pedestals to conserve floor space. Procurement teams should note the unbranded model WS-CR2830-OAK-SG ships with a 40-minute per-set reference assembly time, supporting easy deployment for high-density seating rollouts across growing work environments.

4-Person Cross Modular Partitioned Office Workstation with Integrated Lockable Storage Specifications
