Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2400 x 1200 x 1100 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Single user main worktop size | 1200 x 600 mm | |
| Single user return worktop size | 1000 x 450 mm | |
| Privacy divider height above worktop | 350 mm | |
| Partition panel thickness | 32 mm | |
| Under-desk seated knee clearance height | 670 mm | |
| Knee clearance width per user | 600 mm | |
| Cable grommet diameter | 60 mm | |
| Mobile 3-drawer pedestal size | 400 x 500 x 600 mm | |
| Worktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Modesty panel height | 450 mm | |
| Support leg square section size | 45 x 45 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Total unit net weight | 140 kg | |
|---|---|---|
| Work surface static load capacity | 100 kg | |
| Drawer slide operational cycle life | 50000 cycles | |
| Hinge operational cycle life | 80000 cycles | |
| Work surface abrasion resistance | 2000 cycles | |
| Recommended maximum user weight per station | 120 kg | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop core | E1 grade particleboard (MFC) | |
|---|---|---|
| Worktop finish | Thermally fused light off-white melamine | |
| Edge treatment | 2mm thick PVC edge banding | |
| Structural framing | 1.2mm thick powder-coated black steel | |
| Upper privacy divider | Perforated off-white acrylic/polycarbonate panel | |
| Lower modesty panel | Dark blue fabric-covered particleboard | |
| Drawer pedestal body | 18mm thick melamine-faced MDF | |
| Drawer slides | Full-extension cold-rolled steel ball-bearing slides | |
| Pedestal casters | 50mm diameter twin-wheel nylon casters | |
| Desk leveling feet | 15mm diameter adjustable nylon glides | |
| Cable grommets | ABS plastic round desk grommets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Workstation layout | Two opposite-facing L-shaped work zones separated by central dividers | |
|---|---|---|
| Privacy separation | 350mm high perforated dividers block direct line of sight between users | |
| Storage configuration | One 3-drawer mobile pedestal per user, located under return worktop | |
| Pedestal mobility | Four twin-wheel casters per pedestal, two with brake locks | |
| Cable management | Round 60mm grommets on each main worktop connect to under-desk raceway | |
| Floor leveling | Adjustable glides on all desk support legs compensate for uneven floor surfaces | |
| Modular assembly | Knock-down panelized design allows reconfiguration of workstation layout | |
| Drawer operation | Full-extension ball-bearing slides allow full access to drawer contents | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office spaces | Provides individual work zones for two staff in low-divider open office layouts | |
|---|---|---|
| Small business admin areas | Compact footprint fits small offices needing two dedicated work positions | |
| Start-up collaborative offices | Balances individual work space with low dividers that support easy communication | |
| Call center or back-office work areas | Standard ergonomic height supports long-duration seated computer work | |
| Temporary or project office setups | Modular knock-down design allows fast deployment and reconfiguration | |
| Recommended paired seating | Standard mid-back swivel task chairs with 5-star base and adjustable height |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables: dimensional safety and strength requirements | |
|---|---|---|
| EN 527-2:2019 | Office work tables: mechanical safety and structural durability requirements | |
| EN 1335-1:2020 | Office work seating (for paired task chairs): dimensional ergonomic requirements | |
| EN 15372:2008 | Office furniture: storage units, strength and durability requirements for pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office products: desks, performance and safety testing standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Office products: storage units, performance and safety testing for pedestals | |
| ANSI/BIFMA X5.1-2017 | Office chairs (for paired task chairs): general purpose office chair safety standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and panel construction | |
|---|---|---|
| GB/T 3327-2019 | Office furniture: desks, applicable to dimensional and performance requirements for work surfaces | |
| GB 18584-2001 | Indoor decorating and refurbishing materials: limit of harmful substances in wood furniture | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables: strength and durability assessment |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and panel construction; 2. GB/T 3327-2019: Office furniture: desks, applicable to dimensional and performance requirements for work surfaces; 3. GB 18584-2001: Indoor decorating and refurbishing materials: limit of harmful substances in wood furniture; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables: strength and durability assessment; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
