Automatic mm / inch conversion · Core engineering specifications
| Overall cluster dimensions | 3020 x 1530 x 1200 mm | |
|---|---|---|
| Work surface height | 762 mm | |
| Single work surface depth (straight leg) | 610 mm | |
| Work surface thickness | 38 mm | |
| Partition panel total height | 1200 mm | |
| Vented upper panel height | 200 mm | |
| Lower modesty panel height | 650 mm | |
| Mobile pedestal dimensions per station | 400 x 500 x 654 mm | |
| Caster diameter (pedestal) | 50 mm | |
| Knee clearance height under desktop | 670 mm | |
| Knee clearance width at curved inner corner | 800 mm | |
| Cable grommet diameter | 60 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total product weight (2-station cluster) | 280 kg | |
|---|---|---|
| Recommended static load per work surface | 91 kg | |
| Drawer static load per pedestal | 25 kg | |
| Recommended user capacity | 2 people | |
| Surface wear resistance | 2000 cycles | |
| Fabric panel sound dampening NRC | 0.35 | |
| Caster rolling durability | 20000 cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | Particleboard core with thermally fused melamine laminate | |
|---|---|---|
| Work surface edge banding | 2 mm thick PVC edge banding | |
| Partition panel lower/full covering | Polyester fabric upholstery over hardboard core | |
| Partition upper vented section | Perforated steel mesh with silver powder-coated frame | |
| Structural support frame | 1.2 mm thick cold-rolled steel with epoxy powder coating | |
| Mobile pedestal body | 0.8 mm thick steel cabinet with matching laminate drawer front | |
| Pedestal casters | Black nylon twin-wheel casters, two lockable per unit | |
| Hardware fasteners | Zinc-plated steel screws and connection brackets | |
| Modesty panel (desk underside) | Fabric-covered matching hardboard panel | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Mobile pedestal storage per station | 2-drawer lockable unit with one utility drawer and one filing drawer | |
|---|---|---|
| Cable management system | Desktop grommets and under-desk cable routing channels | |
| Partition privacy function | 1200 mm mid-height panels block seated line of sight between stations | |
| Pedestal mobility function | Four casters per pedestal allow repositioning under desk or to adjacent work area | |
| Modular assembly function | Bolt-together panel and frame system supports future reconfiguration of workstation layout | |
| Curved inner corner design | Rounded front desktop edge provides increased forearm support during extended computer use | |
| Work surface surface function | Stain, scratch, and impact resistant laminate finish suitable for daily office use | |
| Partition acoustic dampening | Fabric-covered panels reduce reflected office noise between adjacent workstations | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Provides semi-private workspaces for administrative, finance, or operations teams | |
|---|---|---|
| Small business office layouts | Compact 2-person cluster fits efficiently in limited floor space without permanent construction | |
| Call center or customer service hubs | Mid-height partitions reduce cross-talk distraction while allowing supervisor visibility | |
| Startup co-working spaces | Modular design supports flexible reconfiguration as team size changes | |
| Recommended seating pairing | Standard adjustable swivel office chairs with 520 mm seat height | |
| Recommended accessory pairing | Monitor arms, under-desk CPU holders, and desk lamps compatible with grommet cable ports |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to work surface and frame performance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture work chair dimensions reference for seated knee clearance design | |
| EN 1022:2018 | Furniture seating strength and durability reference for desk edge load validation | |
| EN 13986:2004 | Wood-based panels for structural use, applicable to work surface and partition board cores |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for load, stability, and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.6-2022 | Panel systems performance standard for cubicle partition strength and connection | |
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for mobile pedestal drawer load and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate desk surfaces and panel components | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable to steel frames and pedestal cabinets | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to board substrates | |
| GB/T 11718-2021 | Medium density fiberboard/particleboard performance requirements, applicable to desk core material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate desk surfaces and panel components; 2. GB/T 3325-2017: General technical requirements for metal furniture, applicable to steel frames and pedestal cabinets; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to board substrates; 4. GB/T 11718-2021: Medium density fiberboard/particleboard performance requirements, applicable to desk core material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
