PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	4200 × 1500 × 1100 mm
Overall cluster dimensions	4200 x 1500 x 1100 mm
Single L-shaped workstation worktop width (main section)	1400 mm
Single L-shaped workstation worktop depth	700 mm
Work surface height from floor	750 mm
Privacy partition total height	1200 mm
Worktop panel thickness	25 mm
Mobile pedestal dimensions	420 x 600 x 580 mm
Seated knee clearance height under worktop	600 mm
Seated knee clearance width per station	700 mm
Partition panel thickness	100 mm
Edge banding thickness	2 mm
Metal support frame wall thickness	1.5 mm
Cable grommet diameter per work station	80 mm
Slatted upper vent section height on partitions	300 mm
Caster diameter on mobile pedestals	75 mm
Primary Component Thickness	40 mm according to load-bearing role

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total cluster net weight	120 kg
Worktop static uniform load capacity	150 kg
Single mobile pedestal drawer dynamic load rating	23 kg
Ball-bearing drawer slide cycle rating	50000 cycles
Partition hinge/connector cycle rating for reconfiguration	1000 cycles
Worktop surface abrasion resistance rating	2000 cycles
Recommended maximum user count	3
Standard commercial product warranty	5 years
Partition connector reconfiguration cycle rating	1000 cycles
Worktop melamine surface abrasion resistance	2000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface panels	25mm E1 grade melamine-faced particle board, light oak wood grain finish
Structural support frame	1.5mm thick powder-coated dark bronze steel, welded corner connections
Lower partition panel facing	Sage green woven fabric upholstery over acoustic softboard core
Upper partition vent section	Horizontal dark metal slats with matching sage green fabric backing
Mobile pedestal drawer fronts	Sage green melamine-faced engineered wood matching partition finish
Mobile pedestal carcass	16mm light oak grain melamine-faced engineered wood
Worktop and modesty panel edges	2mm thick PVC edge banding, color-matched to light oak finish
Mobile pedestal casters	75mm diameter black nylon swivel casters, 2 locking per unit
Drawer hardware	Cold-rolled steel ball-bearing full-extension drawer slides
End privacy modesty panels	16mm light oak grain melamine-faced engineered wood, fixed to frame
Lock cores for mobile pedestals	Keyed alike cylinder locks with 2 keys per pedestal
Mobile pedestal lock cores	Keyed alike cylinder locks with 2 keys per pedestal

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Modular cluster configuration	Pre-configured 3-staff F-pod layout, supports reconfiguration to other pod sizes via standard connectors
Mobile pedestal storage	Each station includes 3-drawer rolling pedestal, fits fully under worktop with lockable top drawer
Privacy separation	Partial-height 1200mm dividers block seated line of sight between adjacent workstations
Curved ergonomic worktop edge	Rounded inner L-corner edge reduces pressure points during extended seated work
Cable management	Pre-drilled 80mm cable grommets at each work corner route power/data cords under the work surface
Mobile pedestal mobility	Swivel casters allow pedestals to be pulled out for access or repositioned within the workspace
Ventilated partition design	Slatted upper partition sections allow air circulation between workstations while maintaining privacy
Leveling adjustment	Adjustable feet on frame base compensate for uneven office flooring during installation
Modular configuration	Pre-configured 3-staff F-pod layout, supports reconfiguration via standard steel connectors
Seated privacy separation	1200mm partial-height dividers block direct seated line of sight between adjacent stations
Ergonomic curved worktop edge	Rounded inner L-corner front edge reduces forearm pressure during extended seated work
Integrated cable management	Pre-drilled 80mm cable grommets at each work corner route power/data cords under surfaces

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office staff zones	Suitable for 3-person administrative/operational teams in open offices, balances privacy and collaboration
Startup team work areas	Ideal for small agile teams, modular design supports quick layout adjustments as headcount changes
Corporate back-office departments	Recommended for finance, HR and admin teams requiring individual work surfaces and locked storage
Co-working dedicated desk zones	Suitable for fixed dedicated desk memberships, provides consistent personal workspace for long-term members
Government/state-owned enterprise offices	Compliant with standard office furniture procurement requirements for low-formaldehyde durable workstations

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

BS EN 1335-3	2000: Office furniture safety requirements, applicable to structural safety inspection

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Recommended for worktop static load and durability acceptance for commercial office use
ANSI/BIFMA X5.9-2019	Recommended for mobile pedestal storage unit load and drawer cycle performance

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to worktop and storage panel quality inspection
GB 18580-2017	Formaldehyde emission limit for wood-based panels, applicable to E1 grade panel material acceptance
GB/T 35607-2017	General technical requirements for office furniture workstations, applicable to overall structural performance checks

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and storage panel quality inspection;
2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to E1 grade panel material acceptance;
3. GB/T 35607-2017: General technical requirements for office furniture workstations, applicable to overall structural performance checks;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · CUB-F3-L-OAK-SG

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · CUB-F3-L-OAK-SG

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · CUB-F3-L-OAK-SGOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The 3-Staff F-Pod L-Shaped Modular Office Cubicle Workstation Cluster with Mobile Pedestals, model CUB-F3-L-OAK-SG, is an unbranded modern office furniture solution designed to balance individual privacy and cross-team collaboration. Visually, the cluster adopts a streamlined L-shaped layout with a light oak wood grain finish on work surfaces, paired with dark bronze structural frames and soft sage green partition panels, creating a warm, professional aesthetic that complements contemporary office interiors. Partial-height privacy dividers stand 1200mm tall to block seated line of sight between adjacent users, while horizontal slatted upper sections allow smooth air circulation without compromising visual separation. Each workstation features a rounded inner corner edge to reduce contact pressure during extended seated work. The cluster holds overall dimensions of 4200 x 1500 x 1100 mm, with individual L-shaped workstations offering 1400mm of main section width, 700mm depth, and a standard 750mm work surface height with 600mm of seated knee clearance below. The structure is built with 25mm thick E1 grade melamine-faced particle board worktops finished with 2mm color-matched PVC edge banding, supported by a 1.5mm thick powder-coated dark bronze steel frame with welded corner connections for stable support. Partition panels combine a sage green woven fabric upholstered acoustic softboard lower section with slatted upper vents lined with matching fabric. Each station comes with a dedicated 3-drawer mobile pedestal measuring 420 x 600 x 580 mm, built with 16mm light oak grain melamine carcass, sage green melamine drawer fronts, cold-rolled steel full-extension ball-bearing slides, and 75mm black nylon swivel casters (two locking per unit) that let the pedestal slide fully under the worktop for space efficiency. Functional design elements include pre-drilled 80mm cable grommets at each work corner to route power and data cords out of sight, a lockable top drawer on each mobile pedestal for secure personal storage, and standard connectors that support reconfiguration to alternate pod sizes as workspace needs evolve. Worktops support a 150kg static uniform load, each pedestal drawer holds a 23kg dynamic load, drawer slides are rated for 50000 open-close cycles, partition connectors support 1000 reconfiguration cycles, and work surfaces deliver 2000 cycles of abrasion resistance for long-term daily use. The cluster is well suited for open-plan office staff zones for 3-person administrative or operational teams, agile startup work areas, corporate back-office departments including finance, HR and administration, fixed dedicated desk zones in co-working spaces, and government or state-owned enterprise offices meeting standard low-formaldehyde durable furniture procurement requirements. For procurement, note that each set ships in 2 cartons with 0.8m³ packaging volume, 120kg packaged gross weight, and requires 40 minutes of assembly time per unit. The E1 grade material meets low-formaldehyde requirements for standard commercial office fit-outs, and the modular design supports future layout adjustments to align with changing team sizes.

3-Staff F-Pod L-Shaped Modular Office Cubicle Workstation Cluster with Mobile Pedestals Specifications
