Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint (W x D x total H) | 1420 x 1420 x 1200 mm | |
|---|---|---|
| Work surface height above floor | 750 mm | |
| Desktop thickness | 25 mm | |
| Seated knee clearance height | 580 mm | |
| Partition privacy screen total height | 450 mm above desktop | |
| Mobile 3-drawer pedestal dimensions (W x D x H) | 420 x 490 x 660 mm | |
| Pull-out keyboard tray travel extension | 300 mm | |
| Cable grommet diameter | 60 mm | |
| Side support panel thickness | 18 mm | |
| Caster wheel diameter | 50 mm | |
| Curved corner inner work radius | 300 mm | |
| Partition frame wall thickness | 1.2 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed desktop static load capacity | 100 kg | |
|---|---|---|
| Recommended user weight capacity | 150 kg | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Drawer slide cycle durability | 50000 open/close cycles | |
| Total product net weight (desk + screen + pedestal) | 95 kg | |
| Limited manufacturer warranty period | 10 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | E1-grade engineered particleboard with thermally fused melamine laminate, 2mm ABS edge banding | |
|---|---|---|
| Partition screen frame | Powder-coated silver aluminum alloy profile, 1.2mm wall thickness | |
| Lower partition panel | Flame-retardant green woven fabric upholstery over rigid core | |
| Upper partition panel | Translucent horizontal slatted polycarbonate panel | |
| Mobile pedestal body | E1-grade engineered board, light wood drawer fronts with white side panels, central locking system | |
| Support base hardware | Powder-coated steel leveling feet, 50mm dual-wheel nylon brake casters |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Pull-out keyboard tray | Mounted under curved corner, extends 300mm for typing, retracts flush when not in use | |
|---|---|---|
| Mobile pedestal locking | Central cam lock secures all 3 drawers, 2 utility drawers + 1 hanging file drawer with full-extension slides | |
| Cable management | 60mm desktop cable grommet + 3 rear modesty panel wire access ports for cord routing | |
| Leveling adjustment | Threaded nylon glides on fixed desk supports adjust 15mm to compensate for uneven floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office single workstations | Provides individual seated privacy with 450mm high partitions to reduce distraction | |
|---|---|---|
| Small business private staff offices | All-in-one work surface with built-in filing storage fits compact 1.4m square footprints |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2016 | Office work tables - Safety, strength and durability requirements, applicable to structural performance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture - Office work chairs, referenced for ergonomic desk-seat compatibility |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Safety and performance standard, applicable to load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural and finish quality | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wood furniture for interior decoration, applicable to formaldehyde emission |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural and finish quality; 2. GB 18584-2001: Limit of harmful substances in wood furniture for interior decoration, applicable to formaldehyde emission; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
