Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Worktop thickness | 25 mm | |
| Privacy partition height | 1200 mm | |
| Knee clearance height under work surface | 673 mm | |
| Single work surface depth | 600 mm | |
| End storage pedestal dimensions | 400 x 600 x 673 mm | |
| Center perforated divider thickness | 32 mm | |
| Edge banding thickness | 2 mm | |
| Tapered support leg height | 100 mm | |
| Cable grommet diameter | 60 mm | |
| Drawer internal height | 150 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total unit net weight | 130 kg | |
|---|---|---|
| Static load per work surface | 91 kg | |
| Drawer slide static load capacity | 25 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Surface scratch resistance | 2000 revolutions | |
| Recommended maximum user weight per station | 136 kg | |
| Manufacturing defect warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | E1-grade melamine-faced particle board | |
|---|---|---|
| Edge banding | 2mm thick PVC edge trim | |
| Privacy partition panels | Fabric-upholstered tackable board over metal frame | |
| Center divider accent panel | Perforated powder-coated steel panel | |
| Support legs | Powder-coated tapered steel legs | |
| Storage cabinet carcass | Melamine-faced engineered wood | |
| Drawer hardware | Cold-rolled steel slides with integrated key lock | |
| Partition frame | Anodized aluminum extrusion | |
| Desk modesty panels | 18mm thick melamine-faced engineered wood | |
| Foot pads | Adjustable nylon glide feet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Individual lockable storage | One lockable drawer and cabinet pedestal per station to secure personal items | |
|---|---|---|
| Privacy separation | 1200mm tall fabric dividers block line of sight between adjacent workstations | |
| Cable management | 60mm diameter desktop grommets route power and data cables off work surfaces | |
| Leveling adjustment | Nylon glide feet at base adjust 10mm to compensate for uneven floors | |
| Storage configuration | Open top shelf, lockable drawer, and lower closed cabinet per user position | |
| Modular assembly | Knock-down panelized construction connects with cam-lock hardware for reconfiguration | |
| Tackable surface | Fabric partition panels accept push pins for posting notes and documents | |
| Knee well access | Open unobstructed knee space under each work surface for seated task use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office spaces | Separates two staff work positions while reducing cross-desk visual distraction | |
|---|---|---|
| Call center and admin departments | Provides dedicated individual storage and work surface for daily task work | |
| Small startup office layouts | Compact L-shape fits corner spaces to maximize floor area efficiency | |
| Hot-desking shared work areas | Lockable storage secures personal items between different user shifts | |
| Staff training rooms | Two independent work surfaces accommodate paired training activities | |
| Back-office administrative zones | Durable laminate surface resists daily wear from regular office equipment use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial desk performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables, dimensional requirements for seated work surface clearance | |
| EN 1335-2:2009 | Office furniture stability requirements applicable to freestanding workstation units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for structural performance and load testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer slide durability and lock performance | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and recycled content |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel structural performance | |
|---|---|---|
| GB/T 3327-2016 | Office desks and tables, applicable to work surface dimensional and stability requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1-grade board acceptance | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture coatings, applicable to melamine top finish |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel structural performance; 2. GB/T 3327-2016: Office desks and tables, applicable to work surface dimensional and stability requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1-grade board acceptance; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture coatings, applicable to melamine top finish; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
