PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2840 × 1440 × 1150 mm
Overall footprint dimensions	2840 x 1440 x 1150 mm
Work surface height from finished floor	750 mm
Single work surface dimensions per user	1400 x 600 mm
Privacy partition panel thickness	60 mm
Melamine work surface thickness	25 mm
PVC edge banding thickness	2 mm
Knee clearance height under work surface	650 mm
Mobile pedestal dimensions per unit	400 x 500 x 600 mm
Desktop cable grommet diameter	80 mm
Partition support steel leg wall thickness	1.2 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Work surface distributed static load capacity	91 kg
Drawer slide operational cycle rating	50000 cycles
Pedestal lock cylinder cycle rating	10000 cycles
Total product net weight	145 kg
Fabric partition sound absorption coefficient (NRC)	0.35
Work surface abrasion resistance rating	2000 cycles
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface substrate	E1 grade melamine-faced particleboard (MFC)
Work surface edge treatment	2mm thick PVC edge banding, hot-melt glued
Partition panel frame	6063-T5 aluminum alloy extrusions, powder coated black
Partition panel infill	Particleboard core wrapped in blue woven polyester fabric
Structural support legs	1.2mm thick cold-rolled steel, powder coated black, with adjustable leveling feet
Mobile pedestal body	0.8mm thick cold-rolled steel with light gray and blue powder coat finish
Drawer slides	Cold-rolled steel undermount soft-close slides
Drawer hardware	Zinc alloy lock core, black curved ABS drawer pulls
Cable management components	ABS plastic cable grommet and under-desk plastic raceway
Pedestal casters	50mm diameter black nylon swivel casters (2 with brake)
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness	2 mm

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Modular cubicle layout	L-shaped two-seat corner cluster with full side and divider privacy panels
Under-desk mobile storage	Two-drawer pedestal per user, lockable top stationery drawer, lower hanging file drawer
Cable management system	Round desktop cable grommet paired with under-desk plastic wire raceway
Adjustable floor leveling	Threaded steel leveling feet on all support points
Desktop privacy screens	Short frosted acrylic screens mounted at partition top edges
Knock-down assembly design	Cam-lock and bolted panel connections for on-site assembly
Mobile pedestal mobility	Four swivel casters per pedestal, two with locking brakes
Drawer soft-close mechanism	Self-suction dampers on both drawer slides per pedestal
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open plan office staff work areas	Two-seat L-cluster fits corner positions to maximize open office floor space
Small business administrative departments	Two dedicated workstations with integrated storage for HR, finance or admin teams
Call center and shared work hubs	Low partition height supports team visibility while maintaining personal work zones
Temporary project office setups	Modular knock-down design allows disassembly and reconfiguration for short-term project spaces
Co-working space dedicated desks	Lockable pedestals secure personal items for assigned co-working members

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office furniture safety and strength	EN 527:2002+A1:2019
Office storage furniture performance	EN 14073:2004
Office furniture fire resistance	EN 1021:2014

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Office desk performance standard	ANSI/BIFMA X2021
Mobile storage pedestal performance	ANSI/BIFMA X2022

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Office desk dimensional standard	GB/T 3326
Wood-based panel formaldehyde emission	GB 18580
Office furniture mechanical stability	GB/T 10357.1
Office hardware durability test	GB/T 24821

Standardized tender description text

This product must meet the following technical requirements:
1. Office desk dimensional standard: GB/T 3326;
2. Wood-based panel formaldehyde emission: GB 18580;
3. Office furniture mechanical stability: GB/T 10357.1;
4. Office hardware durability test: GB/T 24821;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · L2-CUB-2840-BLU

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · L2-CUB-2840-BLU

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · L2-CUB-2840-BLUOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The 2-Person L-Shaped Office Cubicle Workstation with Mobile Pedestals (model L2-CUB-2840-BLU, unbranded) is a purpose-built modular workspace solution designed to balance privacy, collaboration, and space efficiency across professional settings. Configured as a compact L-shaped two-seat corner cluster, the unit features full side and center divider privacy panels wrapped in blue woven polyester fabric, framed by powder-coated black 6063-T5 aluminum alloy extrusions. Short frosted acrylic screens mounted along the partition top edges preserve sightlines for team coordination while defining distinct personal work zones, and the overall structure sits on 1.2mm thick cold-rolled steel support legs with threaded adjustable leveling feet to accommodate uneven floor surfaces. Each user is allocated a 1400 x 600 mm melamine-faced particleboard worksurface positioned 750 mm from the finished floor, with 650 mm of clear knee clearance underneath. The 25 mm thick worksurfaces are finished with 2 mm hot-melt glued PVC edge banding to resist impact damage, and paired with integrated cable management components including round desktop ABS grommets and under-desk plastic raceways to organize power and data cords out of sight. Each station includes a matching two-drawer mobile pedestal constructed from 0.8mm thick cold-rolled steel with a light gray and blue powder coat finish, fitted with four swivel casters (two with locking brakes) for flexible repositioning. Every pedestal features a lockable top stationery drawer secured by a zinc alloy lock core, a lower hanging file drawer, and black curved ABS pulls, mounted on cold-rolled steel undermount soft-close slides for smooth operation. The unit is suitable for a range of commercial environments: its corner-aligned footprint fits neatly into open plan office staff areas to maximize usable floor space, while its integrated lockable storage supports the needs of small business HR, finance, and administrative teams. The moderate partition height balances visibility and personal space for call centers and shared work hubs, the knock-down cam-lock and bolted assembly allows disassembly and reconfiguration for temporary project offices, and the lockable storage makes it a practical choice for dedicated co-working desks. When planning procurement, note that the unit ships knock-down for on-site assembly, with a reference assembly time of 40 minutes per set. The structure supports a 150 kg uniformly distributed top static load, with worksurfaces rated for 91 kg of distributed static load, and fabric partitions carry a 0.35 NRC sound absorption rating to reduce ambient cross-talk. All connections use durable cam-lock and bolted fasteners for long-term structural stability across reconfigurations.

2-Person L-Shaped Office Cubicle Workstation with Mobile Pedestals Specifications
