| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 1550 x 1550 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Worktop thickness | 25 mm | |
| Partition frame wall thickness | 1.2 mm | |
| Upper frosted glass panel thickness | 5 mm | |
| Lower fabric partition panel thickness | 40 mm | |
| Fixed storage pedestal dimensions | 400 x 550 x 725 mm | |
| Knee clearance height under worktop | 700 mm | |
| Cable grommet diameter | 80 mm | |
| Drawer front height (upper pencil drawer) | 150 mm | |
| Drawer front height (lower file drawer) | 300 mm | |
| Edge banding thickness | 2 mm | |
| Adjustable foot height adjustment range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Worktop uniform static load capacity | 80 kg | |
|---|---|---|
| Drawer slide open/close cycle rating | 50000 cycles | |
| Frosted glass panel light transmittance | 50% | |
| Surface scratch resistance rating | 2000 cycles | |
| Maximum recommended seated user weight | 136 kg | |
| Formaldehyde emission limit | 0.124 mg/m³ | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm melamine-faced MFC panel, light oak finish, 2mm PVC edge banding | |
|---|---|---|
| Partition frame | 1.2mm thick extruded aluminum alloy, white powder-coated finish | |
| Upper partition panel | 5mm frosted tempered safety glass, anti-glare finish | |
| Lower partition panel | 40mm thick fabric-wrapped acoustic panel, neutral grey finish | |
| Pedestal cabinet body | 18mm melamine-faced particleboard, matte white finish | |
| Drawer slides | 3-section full-extension silent steel ball-bearing slides | |
| Drawer handles | Brushed aluminum alloy pull handles, 128mm hole spacing | |
| Cable management grommet | ABS plastic round cable port with brush seal | |
| Leveling feet | Nylon base adjustable glides, steel threaded stem | |
| Rear modesty panel | 18mm grey melamine panel with integrated cable pass-through cutouts | |
| Drawer lock | Zinc alloy centralized cylinder lock, keyed alike | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Right-side fixed pedestal with 1 shallow pencil drawer and 1 deep hanging file drawer | |
|---|---|---|
| Drawer lock function | Single key lock secures both drawers for personal storage security | |
| Cable management | Corner desktop grommet plus rear modesty panel cutouts route power/data cables off work surface | |
| Privacy partition function | 430mm tall lower fabric panel blocks direct sightline to seated workspace, upper frosted glass allows ambient light transmission | |
| Floor leveling | Adjustable nylon feet compensate for ±15mm uneven floor elevation to keep worktop stable | |
| Modular expansion | Aluminum partition frame connects to adjacent matching workstations to form multi-seat cubicle clusters | |
| Knee space access | Curved front worktop cutout provides 700mm clear legroom for ergonomic seated posture | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office staff zones | Suited for daily administrative, clerical, and data entry work with medium privacy separation | |
|---|---|---|
| Call center and shared workspace environments | Fabric lower panel reduces cross-staff visual distraction while glass maintains open office feel | |
| Educational and institutional office spaces | Durable commercial-grade construction meets frequent use requirements for school and government offices | |
| Startup and small business open offices | Compact L-shape fits 900mm minimum aisle width requirements for space-efficient layouts | |
| Adjacent multi-seat cluster configuration | Partition frame connects to matching units to build 2-person, 4-person, or larger cubicle banks |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable for safety, strength, and durability requirements for office worktables and desks | |
|---|---|---|
| EN 1023-2:2000 | Applicable for stability testing of office storage pedestals integrated into workstations | |
| EN 13501-1:2007 | Applicable for fire reaction classification of fabric and panel components for commercial office use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable for performance and durability testing of desk products including load and cycle requirements | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable for performance testing of storage pedestals and drawer units integrated into workstations |
Standards applicable to China-market projects
| GB 18580-2017 | Applicable for formaldehyde emission limits of wood-based panel components used in indoor office furniture | |
|---|---|---|
| GB/T 3324-2017 | Applicable for general technical requirements, dimensional tolerances, and strength testing of wooden office desks | |
| GB/T 35607-2017 | Applicable for green product evaluation criteria for office furniture, including material and emission requirements |
This product must meet the following technical requirements: 1. GB 18580-2017: Applicable for formaldehyde emission limits of wood-based panel components used in indoor office furniture; 2. GB/T 3324-2017: Applicable for general technical requirements, dimensional tolerances, and strength testing of wooden office desks; 3. GB/T 35607-2017: Applicable for green product evaluation criteria for office furniture, including material and emission requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
