Automatic mm / inch conversion · Core engineering specifications
| Overall footprint including partitions | 1500 x 1400 x 1200 mm | |
|---|---|---|
| Work surface height (seated use) | 762 mm | |
| Primary work surface width (user-facing) | 1500 mm | |
| Primary work surface depth | 600 mm | |
| Return work surface width (side) | 1400 mm | |
| Return work surface depth | 450 mm | |
| Worktop thickness | 25 mm | |
| Privacy partition height above worktop | 438 mm | |
| Under-desk knee clearance height | 660 mm | |
| Under-desk knee clearance width (central opening) | 700 mm | |
| Left pedestal cabinet width | 400 mm | |
| Open shelf above drawer internal height | 100 mm | |
| Lower fluted cabinet door height | 500 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Static uniform load capacity for work surface | 80 kg | |
|---|---|---|
| Product net weight | 68 kg | |
| Recommended user weight capacity for seated use | 136 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Surface scratch resistance rating | 2 N | |
| Design service life | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | 25mm E0-grade melamine-faced engineered wood with 2mm PVC edgebanding | |
|---|---|---|
| Left pedestal cabinet panels | 18mm melamine-faced engineered wood with fluted light wood finish door | |
| Lockable drawer front | 18mm engineered wood with sage green matte melamine finish | |
| Privacy partition panels | Fabric-upholstered acoustic panel with dark metal frame | |
| Side divider lower panel | 18mm light wood grain melamine panel with dark metal trim | |
| Desk support legs | 30mm diameter dark powder-coated tapered steel legs | |
| Drawer hardware | Zinc alloy lock with black finish, steel ball-bearing full-extension slides | |
| Cable management grommets | ABS plastic circular cable ports with removable covers | |
| Partition frame hardware | Dark grey powder-coated aluminum connector and trim system | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Two-sided privacy dividers | Block direct line of sight between adjacent workstations for seated user privacy | |
|---|---|---|
| Left integrated pedestal storage | Three-tier storage including open supply shelf, lockable utility drawer, lower closed cabinet | |
| Dual desktop cable grommets | Route monitor, laptop and charger cables below work surface to reduce clutter | |
| Lockable drawer mechanism | Secures small personal items and office supplies with integrated key lock | |
| Fixed height seated work surface | Ergonomic fixed height optimized for standard office task chairs at 762mm | |
| Adjustable foot glides | Level the desk on uneven office floors via threaded bottom adjustment on legs | |
| Unobstructed central knee well | Allows free leg movement and swivel chair access without under-desk obstructions | |
| Panel connector system | Allows reconfiguration of dividers for adjacent cubicle bank installation | |
| Lockable utility drawer internal height | 120 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office staff workstations | Provides individual privacy and dedicated storage for general administrative and clerical staff | |
|---|---|---|
| Small startup office individual work areas | Compact L-shape maximizes work surface without occupying excess floor space | |
| Call center agent workstations | Fixed height and integrated storage support long-duration seated computer work | |
| Government or enterprise cubicle banks | Modular partition system allows installation in continuous rows for large staff teams | |
| Temporary project office setups | Knockdown packaging enables fast deployment and reconfiguration for short-term teams | |
| Home office dedicated work zones | Integrated storage and privacy panels separate work from residential living spaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to worktop load and stability verification | |
|---|---|---|
| EN 1335-1:2020 | Office furniture dimensions for seated workstations, applicable to knee clearance ergonomic checks | |
| EN 1023-2:2000 | Storage furniture strength and durability requirements, applicable to pedestal cabinet testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, durability and stability performance testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer cycle and load performance verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to worktop and cabinet panel quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E0-grade board acceptance | |
| GB/T 35607-2017 | Technical requirements for office workstation panel systems, applicable to partition stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worktop and cabinet panel quality inspection; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E0-grade board acceptance; 3. GB/T 35607-2017: Technical requirements for office workstation panel systems, applicable to partition stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
