| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Work surface static load capacity | 100 kg | |
|---|---|---|
| Seating capacity | 4 users | |
| Total workstation net weight | 320 kg | |
| Partition sound transmission class | 20 dB | |
| Product service life | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm thick E1 grade melamine-faced particleboard | |
|---|---|---|
| Partition frame | Anodized aluminum alloy extrusion | |
| Partition lower panel | Fabric-upholstered MDF core | |
| Partition top strip | Frosted polycarbonate panel | |
| Mobile pedestal body | 18mm thick melamine-faced particleboard | |
| Support modesty panels | 18mm thick white melamine particleboard |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Per-user workspace privacy | Low partition dividers separate adjacent workstations to reduce visual distraction | |
|---|---|---|
| Under-desk storage | 4-drawer mobile pedestal per seat rolls out for file and supply access | |
| Integrated central storage | Open shelf compartments along central spine for small item storage | |
| Cable management access | Pre-drilled cable ports on desk surface for power and data routing |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office spaces | Suitable for 4-person team clusters to balance collaboration and individual work privacy | |
|---|---|---|
| Corporate administrative departments | Configured for regular office tasks including document processing and computer work |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables and desks, safety and strength requirements for desk structure | |
|---|---|---|
| EN 1335-1:2020 | Office work chair clearance compatibility, applicable for under-desk legroom dimensions | |
| EN 1022:2018 | Furniture seating stability, applicable for optional mobile chair compatibility |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for work surface load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable for mobile pedestal drawer performance | |
| ANSI/BIFMA X7.1-2020 | Formaldehyde emission standard for office furniture panels |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for desktop and cabinet panel quality | |
|---|---|---|
| GB/T 35607-2017 | Green product evaluation standard for furniture, applicable for formaldehyde emission limits | |
| GB 28007-2011 | Office furniture safety requirements for children and adult use, applicable for structural stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for desktop and cabinet panel quality; 2. GB/T 35607-2017: Green product evaluation standard for furniture, applicable for formaldehyde emission limits; 3. GB 28007-2011: Office furniture safety requirements for children and adult use, applicable for structural stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
