PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2475 × 1425 × 1100 mm
Overall workstation footprint	2475 x 1425 x 1100 mm
Desktop working height	750 mm
Total partition panel height	1200 mm
Per-user desktop surface	1400 x 1200 mm
Desktop panel thickness	25 mm
Partition panel thickness	60 mm
Seated knee clearance height under desktop	650 mm
Mobile pedestal dimensions	400 x 500 x 600 mm
Frosted upper divider height	300 mm
Desktop grommet diameter	80 mm
Base support leg cross-section	50 x 50 mm
Edge banding thickness	3 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Uniform distributed desktop static load capacity	200 kg
Product net weight (excluding office chairs/monitors)	120 kg
Mobile pedestal caster rolling durability	20000 cycles
Workstation design service life	5 years
Surface abrasion resistance	2000 cycles
Number of supported seated users	2
Drawer slide load cycle rating	50000 cycles
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Desktop core and finish	E1 grade melamine-faced particle board, walnut wood grain print
Desktop edge treatment	3 mm thick PVC edge banding, impact-resistant
Lower partition panels	Melamine-faced particle board with black base trim
Upper partition panels	Frosted translucent acrylic louvered panels
Partition frame and support structure	Powder-coated aluminum alloy profiles
Mobile pedestal body	Melamine-faced particle board, matching walnut finish
Pedestal casters	50 mm diameter hard plastic swivel casters
Drawer hardware	Cold-rolled steel ball-bearing drawer slides, keyed lock
Support legs and leveling glides	Powder-coated square steel legs with adjustable nylon glides
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Individual workspace separation	1200 mm tall partitions separate two facing work positions
Under-desk storage configuration	One mobile rolling pedestal per user with lockable drawer and cabinet
Cable management system	80 mm diameter desktop grommets + under-desk plastic cable raceway
Floor leveling adjustment	Adjustable nylon glides on base legs with 15 mm adjustment travel
Pedestal mobility	Four swivel casters per pedestal allow 360-degree movement
Modular assembly design	Knock-down panel construction allows reconfiguration or extension
Storage locking function	Keyed cam lock secures top drawer and lower cabinet on each pedestal
Surface protective performance	Melamine desktop finish resists water, stains and light scratches
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan corporate offices	Provides semi-private individual workspaces for general staff in open office layouts
Startup and small business workspaces	Modular design supports flexible layout adjustments as team size changes
Government and institutional offices	Durable construction and standard dimensions suit long-term administrative work use
Call center and back-office operations	Partition height reduces cross-talk distraction for high-focus repetitive task work
Temporary project team work areas	Knock-down design allows fast installation and relocation for short-term project teams

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office work tables: Safety and strength requirements
EN 12521:2015	Furniture: Strength, durability and safety for non-domestic seating/workspaces
EN 13986:2004+A1:2015	Wood-based panels for construction: Formaldehyde emission classes

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk Products: Safety and performance standard for North American markets
ANSI/BIFMA X5.9-2019	Storage Units: Performance requirements for mobile office pedestals

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden office furniture
GB 18580-2017	Formaldehyde emission limits for wood-based panels
GB/T 3326-2016	Strength and durability test methods for office tables
GB/T 10357.1-2013	Mechanical test methods for furniture stability

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden office furniture;
2. GB 18580-2017: Formaldehyde emission limits for wood-based panels;
3. GB/T 3326-2016: Strength and durability test methods for office tables;
4. GB/T 10357.1-2013: Mechanical test methods for furniture stability;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · CUB-L2-WAL-1412

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · CUB-L2-WAL-1412

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · CUB-L2-WAL-1412Open Export Tool

Quick Actions

Post an RFQ

Product Description

This 2-person L-shaped walnut grain office cubicle workstation delivers a balanced blend of semi-private separation and collaborative accessibility for dual-user setups, configured in a cross-corner layout that maximizes usable floor space. Its visual design pairs warm walnut wood grain finished surfaces with frosted semi-transparent upper partition panels, creating a polished, professional aesthetic that avoids the overly closed feel of solid cubicle systems. Lower partition sections feature matching walnut melamine finishes with black base trim, while upper louvered acrylic panels allow diffused light flow between work zones without compromising individual privacy. Each user is allocated a dedicated desktop surface, positioned facing the shared partition structure to minimize direct visual distraction during focused work. Constructed for consistent daily use, the workstation features E1 grade melamine-faced particle board for all desktop and lower panel components, finished with a printed walnut grain and edged with thick impact-resistant PVC banding to guard against daily wear from contact and equipment placement. Partition support structures use powder-coated aluminum alloy profiles for stable framing, while base supports consist of powder-coated square steel legs fitted with adjustable nylon leveling glides to accommodate uneven floor surfaces. Included mobile pedestals match the walnut finish of the desktops, fitted with hard plastic swivel casters for easy repositioning, and cold-rolled steel ball-bearing drawer slides paired with keyed cam locks to secure stored contents. All assembly hardware is steel for durable long-term connections. Functionality is tailored to modern office needs: 1200mm tall partitions separate the two work positions to reduce cross-talk and visual distraction, while each user receives a dedicated mobile pedestal with a lockable top drawer and lower cabinet for personal and work item storage. An integrated cable management system combines desktop grommets with under-desk plastic raceways to keep power and data cords organized and out of sight. The knock-down modular construction supports easy reconfiguration or extension as spatial needs change, and pedestal casters allow full 360-degree movement to position storage exactly where each user prefers. This workstation is well suited for a range of commercial spaces, including open-plan corporate offices where general staff require semi-private work zones, startup and small business offices that need flexible layouts to adapt to changing team sizes, government and institutional offices for long-term administrative work, call centers and back-office operations where reduced distraction supports high-focus repetitive tasks, and temporary project team areas that benefit from fast installation and easy relocation. For procurement planning, note that each unit ships in two cartons, with a reference assembly time of 40 minutes per set. The product holds a design service life of five years, with tested load capacities for desktops, drawer slides, caster durability and surface abrasion resistance aligned to regular daily office use. The unbranded model uses standard, widely compatible component dimensions to simplify future layout adjustments or additions, and does not include office chairs or monitors as part of the base package.

2-Person L-Shaped Walnut Grain Office Cubicle Workstation with Frosted Dividers and Mobile Pedestals Specifications
