Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation dimensions | 2400 x 600 x 1200 mm | |
|---|---|---|
| Work surface height above floor | 750 mm | |
| Partition height above work surface | 450 mm | |
| Single work surface per user | 1200 x 600 mm | |
| Under-desk knee clearance height | 630 mm | |
| Mobile 3-drawer pedestal dimensions | 420 x 480 x 630 mm | |
| Pull-out keyboard tray dimensions | 550 x 270 mm | |
| Cable grommet diameter | 60 mm | |
| Worktop thickness | 25 mm | |
| Partition aluminum profile width | 43 mm | |
| Caster diameter for mobile pedestals | 50 mm | |
| Adjustable leveling foot height range | 15 mm | |
| Power outlet panel height above floor | 150 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Work surface static load capacity | 100 kg | |
|---|---|---|
| Formaldehyde emission rating | 1.0 mg/L | |
| Work surface transverse static bending strength | 10 MPa | |
| Drawer slide cycle durability | 50000 cycles | |
| Frame service life (commercial use) | 20 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm E1 grade melamine-faced engineered wood with 2mm PVC edge banding | |
|---|---|---|
| Partition frame | 1.5mm thick silver anodized aluminum alloy extrusion | |
| Partition lower panel | 18mm white melamine-faced engineered wood | |
| Partition middle panel | Fabric-upholstered 12mm fiberboard with green finish | |
| Partition upper panel | Translucent white louvered polycarbonate panel | |
| Mobile pedestal body | 17mm melamine-faced engineered wood with lockable metal drawer slides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage function | Two lockable 3-drawer mobile pedestals on casters for personal filing and supplies | |
|---|---|---|
| Keyboard support | Pull-out sliding keyboard tray under each work surface with smooth extension travel | |
| Cable management | Circular desk grommets and rear aluminum cable trough with integrated power outlets | |
| Stability adjustment | Adjustable leveling feet on partition frames to compensate for uneven floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff areas | Two-seat modular workstation for general administrative and clerical staff use | |
|---|---|---|
| Small business team offices | Compact double work unit for startup or small team workspaces with limited floor area |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Safety and performance requirements for office work tables and desks | |
|---|---|---|
| EN 14073-2:2004 | Storage furniture for office use, safety requirements for mobile pedestals | |
| EN 1023-2:2000 | Office furniture screens, mechanical and structural safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for desk products, applicable to work surface load and durability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Performance standard for office storage units, applicable to mobile pedestal testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to worktops and pedestal bodies | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks and workstations, applicable to structural load testing | |
| GB 18584-2001 | Formaldehyde emission limit for interior wood-based finishing furniture, applicable to all board components | |
| GB/T 35607-2017 | Performance requirements for office furniture hardware drawer slides, applicable to pedestal and tray slides |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worktops and pedestal bodies; 2. GB/T 3327-2016: Performance test methods for office desks and workstations, applicable to structural load testing; 3. GB 18584-2001: Formaldehyde emission limit for interior wood-based finishing furniture, applicable to all board components; 4. GB/T 35607-2017: Performance requirements for office furniture hardware drawer slides, applicable to pedestal and tray slides; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
