Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions (W x D x H) | 1600 x 700 x 1200 mm | |
|---|---|---|
| Desktop work surface height | 750 mm | |
| Desktop thickness | 25 mm | |
| Partition panel total thickness | 60 mm | |
| Privacy partition height above desktop | 450 mm | |
| Under-desk seated knee clearance height | 680 mm | |
| Under-desk knee clearance width | 700 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Mobile pedestal dimensions (W x D x H) | 420 x 480 x 650 mm | |
| Caster wheel diameter | 50 mm | |
| Slatted upper vent section height on partitions | 200 mm | |
| Lower solid partition panel height | 750 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 300 kg | |
|---|---|---|
| Pedestal drawer per-drawer static load | 25 kg | |
| Formaldehyde emission rating | 0.037 mg/m³ | |
| Melamine desktop abrasion resistance | 2000 cycles | |
| Partition fabric colorfastness to light | Grade 4 | |
| Drawer slide cycle durability | 50000 open/close cycles | |
| Total workstation net weight (excluding packaging) | 80 kg | |
| Manufacturer limited warranty period | 5 years | |
| Available finish color options | 4 | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | 25mm E0 grade melamine-faced particle board, 2mm PVC edge banding | |
|---|---|---|
| Lower partition solid panels | 16mm melamine-faced particle board, matte light wood finish | |
| Middle partition fabric panels | 15mm medium density fiberboard core, sage green woven fabric upholstery | |
| Upper partition slatted vent panels | Powder-coated steel slats, aluminum alloy frame | |
| Partition support frame | 1.2mm thick powder-coated dark gray steel, aluminum profile connectors | |
| Mobile pedestal body | 16mm E0 grade melamine-faced particle board, matching light wood/sage green finish | |
| Drawer hardware | Cold-rolled steel lock core, low-noise three-section ball-bearing slides | |
| Pedestal casters | 50mm nylon swivel casters, two with locking brakes | |
| Desk support legs | 1.5mm thick square powder-coated steel legs, adjustable leveling feet | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Three-sided privacy partition | Surrounds left, front, right work edges to block line of sight for focused work | |
|---|---|---|
| Cable management grommet | 60mm round desktop port routes power and data cables under the work surface | |
| Lockable mobile storage pedestal | Three-drawer rolling unit fits under desk, central lock secures all contents for personal storage | |
| Pedestal mobility | Four swivel casters (two lockable) allow pedestal to be repositioned or moved for cleaning | |
| Slatted upper partition vents | Permit air circulation between workstations while maintaining upper visual privacy | |
| Modular connection system | Aluminum profile connectors allow linking to additional workstations for multi-seat layouts | |
| Adjustable desk feet | Threaded leveling feet compensate for uneven floor surfaces to keep desktop stable | |
| Surface stain resistance | Melamine desktop and panel finishes resist common office liquid stains for easy cleaning | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office individual workstations | Provides visual privacy to reduce distraction in high-density office layouts | |
|---|---|---|
| Small business staff work areas | Self-contained single unit fits in compact office spaces without built-out construction | |
| Call center focused work positions | Three-sided dividers support focused individual task work and call handling | |
| Startup flexible office layouts | Modular design allows reconfiguration as team size and layout needs change | |
| Temporary project workspaces | Knock-down construction enables fast setup and relocation for short-term project teams | |
| Administrative and clerical work positions | Ergonomic height and integrated storage suit daily paperwork and computer-based tasks |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to desktop load and stability | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic dimensions for seated work, applicable to desk height and clearance | |
| EN 1023-2:2000 | Office storage furniture safety requirements, applicable to mobile pedestal performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to static load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to mobile pedestal load and drawer cycle performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to MFC/MDF panel components | |
| GB/T 3327-2017 | Performance requirements for office desks and workstations, applicable to load and stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to MFC/MDF panel components; 3. GB/T 3327-2017: Performance requirements for office desks and workstations, applicable to load and stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
