Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 1600 x 1100 mm | |
|---|---|---|
| Main work surface height | 750 mm | |
| Main work surface thickness | 25 mm | |
| Work surface edge banding thickness | 2 mm | |
| Seated knee clearance width | 800 mm | |
| Seated knee clearance height | 650 mm | |
| Desk-mounted privacy divider height | 350 mm | |
| Metal support frame wall thickness | 1.5 mm | |
| Return storage unit width | 1200 mm | |
| Return storage unit depth | 450 mm | |
| Drawer internal dimensions | 380 x 350 x 100 mm | |
| Lower cabinet door dimensions | 380 x 600 mm | |
| Cable grommet diameter | 80 mm | |
| Open shelf compartment height | 300 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Work surface static load capacity | 91 kg | |
|---|---|---|
| Leveling glide adjustment range | 10 mm | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface core | High-density particleboard core with walnut-grain melamine facing | |
|---|---|---|
| Frame and structural supports | Powder-coated dark gray steel square tubing with welded joints | |
| Privacy divider lower panel | Beige melamine-faced engineered wood modesty panel | |
| Privacy divider upper screen | Translucent ribbed acrylic panel with aluminum trim | |
| Storage cabinet body | Two-tone walnut and beige melamine-faced engineered wood | |
| Drawer and cabinet hardware | Black matte steel pull handles and recessed drawer pulls | |
| Edge banding | 2mm thick PVC edge banding matching work surface finish | |
| Leveling feet | Nylon-tipped adjustable steel glide feet | |
| Open shelf panels | 18mm thick melamine-faced engineered wood fixed shelves | |
| Cable grommets | Black ABS plastic rectangular cable ports | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Dual recessed rectangular grommets route power and data cables from work surface to under-desk area | |
|---|---|---|
| Storage configuration | Three open fixed shelves, one pull-out supply drawer, one lower enclosed hinged-door cabinet | |
| Leveling adjustment | Four corner-mounted nylon glides adjust up to 10mm to stabilize the desk on uneven floors | |
| Privacy screening | Desk-mounted divider blocks direct sightlines between adjacent seated workers in open offices | |
| Modesty protection | Solid lower panel extends from work surface to lower frame to block leg visibility | |
| Work surface layout | 90-degree L-shaped work surface supports multi-monitor setups with side return for secondary tasks | |
| Drawer operation | Side-mounted drawer slides provide smooth extension for office supply access | |
| Cabinet access | Single hinged door opens 110 degrees for full access to lower enclosed storage space | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office workstations | Desk-mounted divider provides visual privacy for adjacent seated staff in open office layouts | |
|---|---|---|
| Small business private offices | Integrated storage eliminates need for separate cabinets, suitable for compact individual offices | |
| Home office workspaces | Walnut/beige two-tone finish matches residential decor while offering commercial-grade functionality | |
| Coworking space dedicated desks | Durable laminate finish and fixed storage suit long-term assigned coworking desk assignments | |
| Call center seating pods | Compact L-shaped layout fits dense call center floor plans with required cable management | |
| Administrative staff work areas | Mixed open and closed storage supports filing and supply storage for administrative roles |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks safety and strength requirements for commercial use | |
|---|---|---|
| EN 527-2:2016 | Office work tables mechanical performance and dimensional requirements for ergonomic use | |
| EN 13722:2004 | Furniture storage units mechanical performance and structural stability requirements | |
| EN 71-3:2019 | Migration of certain elements for furniture surface finishes, applicable for indoor air safety |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products static load, durability and stability performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Standard for storage units drawer and cabinet performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and finish quality | |
|---|---|---|
| GB/T 3327-2023 | Performance test methods for office desks, applicable to static load and durability testing | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to formaldehyde emissions | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to strength and stability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and finish quality; 2. GB/T 3327-2023: Performance test methods for office desks, applicable to static load and durability testing; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to formaldehyde emissions; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to strength and stability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
