Automatic mm / inch conversion · Core engineering specifications
| Overall cluster footprint | 4263 x 2463 x 1200 mm | |
|---|---|---|
| Finished work surface height | 750 mm | |
| Single L-station main work surface length | 1600 mm | |
| Work surface thickness | 25 mm | |
| Partial privacy partition total height | 1200 mm | |
| Partition panel thickness | 32 mm | |
| Seated knee clearance height under desk | 650 mm | |
| Seated knee clearance width per station | 600 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| PVC edge banding thickness | 2 mm | |
| Partition aluminum frame wall thickness | 1.0 mm | |
| Caster diameter for mobile pedestals | 50 mm | |
| Upper partition slotted accent strip height | 150 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total workstation assembly static load capacity | 300 kg | |
|---|---|---|
| Per-caster dynamic load rating | 50 kg | |
| Supported seated users per cluster | 6 | |
| Work surface abrasion resistance cycles | 2000 cycles | |
| Partition fabric flame retardant rating | Class B | |
| Work surface heat resistance temperature | 120 °C | |
| Net weight per complete 6-station cluster | 380 kg | |
| Standard product warranty duration | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface core | E1 grade low-formaldehyde particleboard | |
|---|---|---|
| Work surface finish | Scratch-resistant melamine laminate with near-color 2mm PVC edge banding | |
| Partition frame | 1.0mm thick aluminum alloy with electrostatic powder-coated gray finish | |
| Partition facing | Tackable light gray linen-look fabric panel over particleboard core | |
| Mobile pedestal cabinet body | 18mm thick E1 melamine-faced particleboard | |
| Mobile pedestal hardware | Steel keyed drawer lock with plastic pull handle | |
| Mobile pedestal casters | Black nylon swivel casters, 2 per cabinet with brake, 2 without | |
| Modular connecting hardware | Powder-coated steel knock-down brackets and cam locks | |
| Modesty panel under work surface | 18mm thick matching melamine particleboard | |
| Upper partition accent strip | Rigid gray slotted plastic grille for ventilation and visual accent | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration | Knock-down aluminum frame and panel system supports repeated assembly and layout changes | |
|---|---|---|
| Under-partition cable management | Integrated concealed raceway channels route power and data cables between stations and central floor outlets | |
| Mobile pedestal storage | Each station includes one lockable drawer for office supplies and one lower cabinet for hanging file storage | |
| Pedestal mobility | Four swivel casters allow pedestals to be pulled out for access or repositioned under any desk bay | |
| Seated privacy separation | 1200mm high fabric dividers block direct line of sight between adjacent seated workers | |
| Locking storage security | Keyed lock on each mobile pedestal secures personal documents and office supplies at every station | |
| Surface maintenance | Stain-resistant melamine and fabric surfaces wipe clean with standard office cleaning products | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan corporate office zones | Fits 6 staff in individual separated workstations for departmental team layouts | |
|---|---|---|
| Call center and shared service floors | Standardized dimensions support uniform workstation deployment for large teams | |
| Startup and co-working shared spaces | Neutral gray two-tone finish matches modern commercial interior design schemes | |
| Government and institutional office areas | Durable commercial-grade construction withstands daily high-traffic long-term use | |
| Small business general office space | All-in-one cluster includes work surfaces, dividers, and storage for quick deployment | |
| Temporary project team work zones | Knock-down assembly allows fast installation and relocation for short-term projects |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and dimensional requirements, applicable to worksurface height and clearance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture work chair dimensional coordination, applies to knee clearance dimensions for seated use | |
| EN 1022:2018 | Furniture seating and table stability test methods for commercial office use | |
| EN 13501-1:2018 | Fire classification of construction products, applies to partition fabric flame retardance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for load, durability, and structural stability requirements | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for mobile pedestal load and caster durability performance | |
| ANSI/BIFMA M7.1-2011 | Standard test method for formaldehyde emission from office furniture panels | |
| ANSI/BIFMA X7.1-2022 | Formaldehyde emission standard for low-emitting office furniture products |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worksurface and cabinet panel performance | |
|---|---|---|
| GB/T 35607-2017 | Formaldehyde emission limits for green product evaluation of wooden furniture, E1 grade requirement | |
| GB 20286-2006 | Flame retardant requirements for public place furniture upholstered components, applicable to partition fabric | |
| GB/T 14531-2017 | Office furniture dimensional and structural performance requirements for work desks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worksurface and cabinet panel performance; 2. GB/T 35607-2017: Formaldehyde emission limits for green product evaluation of wooden furniture, E1 grade requirement; 3. GB 20286-2006: Flame retardant requirements for public place furniture upholstered components, applicable to partition fabric; 4. GB/T 14531-2017: Office furniture dimensional and structural performance requirements for work desks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
