| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 1600 x 1600 x 1100 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Work surface depth (main segment) | 600 mm | |
| Work surface depth (return segment) | 600 mm | |
| Knee well clearance height | 680 mm | |
| Privacy partition panel height | 450 mm | |
| Upper rear shelf dimensions | 1400 x 400 mm | |
| Mobile pedestal dimensions | 505 x 445 x 581 mm | |
| Partition frame profile thickness | 2.0 mm | |
| Work surface panel thickness | 25 mm | |
| Caster diameter (mobile pedestal) | 50 mm | |
| Adjustable foot height range | 10 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Work surface static load capacity | 91 kg | |
|---|---|---|
| Partition panel sound insulation | 25 dB | |
| Work surface abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 120 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Structural warranty period | 10 years | |
| Available color options | 6 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | Thermally fused melamine laminate over high-density particleboard | |
|---|---|---|
| Lower modesty and side panels | Melamine-laminated MDF, matte white finish | |
| Partition and support frame | Powder-coated white square steel tubing | |
| Upper privacy divider panel | Light beige melamine hardboard panel | |
| Upper rear shelf | Matching beige melamine particleboard | |
| Mobile pedestal body | Cold-rolled steel with powder-coated beige/white finish | |
| Drawer slides | Zinc-plated steel ball-bearing full-extension slides | |
| Pedestal casters | Black nylon swivel casters with brake | |
| Hardware connectors | Zinc-plated steel modular connecting brackets | |
| Edge banding | 2mm thick PVC edge banding matching work surface color | |
| Leveling feet | Reinforced nylon with threaded steel stem | |
| Drawer lock | Keyed cam lock with two keys per unit |
Adjustment / rotation / tilt / mobility / storage features
| Modular assembly system | Demountable panel and frame connections with bolted brackets | |
|---|---|---|
| Mobile pedestal storage | One lockable drawer plus one door compartment on rolling casters | |
| Fixed side storage | One integrated fixed lockable drawer unit on the return side | |
| Cable management | Surface-mounted wire grommet at inner corner of work surface | |
| Floor leveling adjustment | Threaded adjustable feet at all base frame points | |
| Upper shelf storage | Open elevated shelf along rear edge of partition | |
| Privacy screening | Solid mid-height dividers block seated sightlines between workstations | |
| Knee well access | Curved inner corner cutout on work surface | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office work areas | Single-person private workspace that reduces visual distraction in shared offices | |
|---|---|---|
| Small business and startup offices | Compact footprint fits space-efficient layouts for administrative and clerical staff | |
| Finance and administrative departments | Integrated lockable storage secures sensitive documents and office supplies | |
| Call center and customer service floors | Mid-height partitions balance privacy and supervisor visibility | |
| Temporary office fit-outs | Modular demountable design allows fast installation and future reconfiguration | |
| Home office dedicated workspaces | Professional office configuration with organized storage for remote work | |
| Co-working dedicated desk zones | Assigned individual workstations with personal storage for members |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to work surface design | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic dimensions for seated work, applicable to desk height and clearance | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to drawer pedestal units | |
| EN 1022:2018 | Furniture seating and table stability test methods, applicable to overall structural stability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to mobile pedestal drawer performance | |
| ANSI/BIFMA X7.1-2020 | Furniture emissions standard for low chemical emissions, applicable to panel components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to work surfaces and laminate panels | |
|---|---|---|
| GB/T 3327-2017 | Performance standards for office desks and workstations, applicable to structural stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to all board components | |
| GB/T 28202-2011 | Hardware performance standards for furniture locks and drawer slides |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to work surfaces and laminate panels; 2. GB/T 3327-2017: Performance standards for office desks and workstations, applicable to structural stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to all board components; 4. GB/T 28202-2011: Hardware performance standards for furniture locks and drawer slides; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
