PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1590 × 1590 × 1100 mm
Overall footprint (L x D x H)	1590 x 1590 x 1100 mm
Work surface height above floor	750 mm
Main worktop segment depth	600 mm
Return worktop segment depth	450 mm
Knee well clearance height under worktop	650 mm
Privacy partition total height	1100 mm
Slatted upper screen trim height	120 mm
Mobile pedestal dimensions (W x D x H)	400 x 450 x 600 mm
Fixed side return cabinet width	450 mm
Melamine worktop thickness	25 mm
Steel support frame wall thickness	1.2 mm
PVC edge banding thickness	2 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Work surface total static load capacity	150 kg
Mobile pedestal caster dynamic load rating	50 kg
Recommended user weight capacity	120 kg
Worktop surface abrasion resistance	2000 cycles
Formaldehyde emission level	0.05 mg/m³
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Worktop substrate	720 kg/m³ high-density fiberboard
Worktop surface finish	Wear-resistant melamine laminate with 2mm PVC edge banding
Privacy partition panels	Polyester fabric over acoustic fiber fill, B1 flame retardant
Structural support frame	Powder-coated cold-rolled steel, 1.2mm wall thickness
Drawer slides	3-section soft-close cold-rolled steel slides
Drawer locks	Keyed alloy steel cam locks
Mobile pedestal casters	Black hard nylon swivel casters, 2 with brake function
Modular panel connectors	Zinc-plated steel bracket fasteners
Cable management raceways	Powder-coated steel under-desk channels with desktop grommets
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Curved corner work surface	Concave inner curved corner creates ample unobstructed seated workspace
Privacy partition system	1100mm tall fabric screens block seated line of sight for individual work focus
Mobile pedestal storage	Lockable 2-drawer pedestal on swivel casters rolls under main worktop for flexible storage
Fixed side return storage	Integrated lockable drawer cabinet below return work surface for permanent document storage
Modular assembly	Steel bracket connectors allow panel reconfiguration for multi-station cubicle layouts
Cable management	Under-desk raceways and desktop grommets route power and data cables out of sight
Mobile pedestal mobility	Swivel casters allow the pedestal to be repositioned or fully removed from the knee well
Drawer soft-close mechanism	Steel slides include damping buffers to prevent slamming and reduce operational noise
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office layouts	Provides individual work privacy without permanent wall construction for corporate offices
Small business workspaces	Single-station footprint fits compact office areas with integrated storage to save space
Government and institutional offices	Durable commercial-grade construction meets heavy daily use requirements for public sector workspaces
Call center and administrative workstations	Curved work surface and partition screens support focused screen-based work with noise reduction
Co-working flexible offices	Modular construction allows reconfiguration as team sizes and layouts change
Home office professional setups	Commercial-grade durability and built-in storage suit dedicated home workspaces with professional aesthetic

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office work tables and desks - safety, strength and durability requirements
EN 1335-2:2009	Office furniture - office work chair safety, reference for seated work clearance
EN 1022:2018	Domestic and commercial furniture - seating and table stability test methods
EN 13501-1:2018	Fire classification of construction products, applicable to partition fabric rating

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk products performance standard for strength, durability and stability
ANSI/BIFMA X5.6-2022	Panel systems performance standard for modular office cubicle partitions
ANSI/BIFMA M7.1-2019	Standard test method for formaldehyde and VOC emissions from office furniture

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to worktop and cabinet components
GB 18584-2001	Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture
GB/T 10357.1-2013	Furniture mechanical performance test for tables, applicable to desk strength and stability
GB 20286-2006	Flame retardant requirements for public place furniture, applicable to partition fabric

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and cabinet components;
2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture;
3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to desk strength and stability;
4. GB 20286-2006: Flame retardant requirements for public place furniture, applicable to partition fabric;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · L-CUB-1590-WS

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · L-CUB-1590-WS

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · L-CUB-1590-WSOpen Export Tool

Quick Actions

Post an RFQ

Product Description

This single-user curved L-shaped cubicle workstation desk offers a purpose-built corner layout designed to balance individual focus and functional workspace access. Its form features a concave inner curved corner that creates unobstructed seated room across the connected main and return work surfaces, paired with full-height fabric privacy partitions that rise to block seated line of sight, capped with slatted upper trim for a polished visual profile. The integrated fixed storage sits below the return work surface, while a rolling pedestal tucks neatly under the main worktop when not in use, keeping the knee well clear for comfortable seating. The desk is constructed with E0-grade high-density fiberboard worktops finished in wear-resistant melamine laminate, sealed with durable PVC edge banding, and supported by a powder-coated cold-rolled steel frame secured with zinc-plated steel bracket fasteners. Privacy partitions are faced with polyester fabric over acoustic fiber fill with B1 flame-retardant properties, while drawer components use soft-close three-section steel slides, keyed alloy steel cam locks, and the mobile pedestal rides on hard nylon swivel casters, two of which include brake locks. Built-in under-desk powder-coated steel cable raceways paired with desktop grommets keep power and data cords routed out of sight. Practical features include lockable fixed and mobile storage for document and supply security, modular panel connections that support reconfiguration into multi-station layouts, and work surfaces sized to accommodate focused screen-based or paper-based tasks. The work surface supports static loads up to 150kg, the mobile pedestal carries dynamic loads up to 50kg, and the low formaldehyde emission level supports healthy indoor air quality. This workstation suits a wide range of spaces, including open-plan corporate offices where individual privacy is needed without permanent wall construction, compact small business offices, government and institutional workspaces built for heavy daily use, call centers and administrative floors, flexible co-working environments that require layout adaptability, and dedicated professional home offices. For procurement, note that each unit ships in two cartons, with a 40-minute per-set assembly time, and the modular design allows bulk purchasers to plan for scaled multi-station deployments that can be adjusted as team needs shift. The unbranded model delivers commercial-grade durability without premium brand markup, making it suitable for both high-traffic public sector deployments and residential home office upgrades. No additional third-party accessories are required for core functionality, as storage, cable management and privacy features are integrated directly into the base unit.

Single-User Curved L-Shaped Cubicle Workstation Desk with Partition Screens and Storage Specifications
