Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 2920 x 2920 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Individual L-station work surface | 1460 x 600 mm per leg | |
| Knee clearance under work surface | 650 mm | |
| Partition panel thickness | 45 mm | |
| Desktop board thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Mobile 3-drawer pedestal dimensions | 400 x 500 x 600 mm | |
| Upper partition privacy height | 1200 mm | |
| Central divider shelf depth | 400 mm | |
| Cable grommet diameter | 60 mm | |
| Aluminum partition frame thickness | 1.5 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single work surface static load capacity | 90 kg | |
|---|---|---|
| Mobile pedestal drawer static load per drawer | 30 kg | |
| Caster rolling durability cycles | 20000 cycles | |
| Total product net weight | 220 kg | |
| Recommended user weight per station | 150 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Hardware salt spray corrosion resistance | 48 hours | |
| Standard commercial warranty | 6 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface and cabinet panels | E1 grade melamine faced particleboard with scratch-resistant finish | |
|---|---|---|
| Partition frame system | Powder-coated aluminum alloy modular profile | |
| Lower partition panels | Solid MDF core with green fabric/laminate finish | |
| Upper partition sections | Translucent slatted acrylic/glass infill panels | |
| Edge treatment | 2mm thick impact-resistant PVC edge banding, rounded curved user edges | |
| Mobile pedestal hardware | Steel drawer slides, lockable top drawer, 50mm PP swivel casters |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Integrated desk grommets and partition-mounted wire trunking for power/data routing | |
|---|---|---|
| Mobile storage pedestal | 3-drawer lockable unit on casters, fits under desk for flexible filing storage | |
| Privacy partition system | Dual-height panels with translucent upper sections to preserve light while blocking seated sightlines | |
| Central divider shelf | Elevated cross-mounted shelf for shared document or accessory storage |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office areas | Provides 4 individual seated work positions with sightline privacy for team-based work | |
|---|---|---|
| Corporate administrative departments | Integrated storage and cable management supports daily desk-based administrative tasks |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables, safety and dimensional requirements for seated workstations | |
|---|---|---|
| EN 1335-1:2020 | Office furniture, office work chair dimensional coordination for workstation design | |
| EN 15372:2016 | Office furniture, strength, durability and safety requirements for storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products, standard for safety, strength and durability performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units, standard for mobile pedestal and cabinet performance | |
| ANSI/BIFMA X5.6-2016 | Panel systems, standard for modular office partition performance |
Standards applicable to China-market projects
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels used in indoor office furniture | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden office furniture, dimensional and structural standards | |
| GB/T 35607-2024 | Office furniture work surface mechanical performance test methods | |
| GB 18584-2024 | Limit of harmful substances in wooden furniture for indoor use |
This product must meet the following technical requirements: 1. GB 18580-2017: Formaldehyde emission limit for wood-based panels used in indoor office furniture; 2. GB/T 3324-2017: General technical requirements for wooden office furniture, dimensional and structural standards; 3. GB/T 35607-2024: Office furniture work surface mechanical performance test methods; 4. GB 18584-2024: Limit of harmful substances in wooden furniture for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
