6-Person Cross-Shaped Modular Office Cubicle Workstation with Mobile Pedestals (model CUB-CRS6-LW-TL) is listed under L-Shaped Office Desk, with overall dimensions of 3600 × 3600 × 1200 mm and main material of Particle‑board (PB). Load capacity: 1200 kg. Certifications: modular,structure,partial-height,privacy,dividers,integrated,power,outlets,rolling,mobile,storage. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 3600 x 3600 x 1200 mm | |
|---|---|---|
| Desktop height from floor | 750 mm | |
| Single workstation width | 1200 mm | |
| Single workstation depth | 600 mm | |
| Partition total height | 1200 mm | |
| Partition thickness | 57 mm | |
| Desktop thickness | 25 mm | |
| Under-desk knee clearance height | 730 mm | |
| Under-desk knee clearance depth | 630 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Frosted glass upper panel height | 450 mm | |
| Solid lower partition panel height | 750 mm | |
| Drawer slide length | 450 mm | |
| Caster diameter for mobile pedestals | 50 mm | |
| Power outlet mounting height | 100 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total workstation static load capacity | 1200 kg | |
|---|---|---|
| Mobile pedestal caster load rating per caster | 40 kg | |
| Surface scratch resistance | 2000 cycles | |
| Commercial warranty period | 5 years | |
| Available finish color count | 30 | |
| Production lead time | 28 days | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm melamine-faced particleboard with PVC edge banding | |
|---|---|---|
| Partition frame | 1.2mm wall thickness aluminum alloy profile | |
| Upper partition infill | 5mm teal-tinted frosted striped tempered glass | |
| Lower partition infill | 0.6mm thick steel panel with off-white powder coat | |
| Mobile pedestal | 0.8mm steel body with matching melamine top, 3 drawers | |
| Cable management raceway | PVC channel integrated into partition base |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Privacy division | Partial-height cross partitions separate 6 individual seated work positions | |
|---|---|---|
| Cable management | Base-integrated raceways route power and data cables to desk-level outlets | |
| Mobile storage | Lockable 3-drawer pedestals on swivel casters roll under each desk | |
| Modular assembly | Pre-fabricated partition and desk panels connect with integrated hardware |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff areas | Provides dedicated separated workspaces for teams of 6 employees | |
|---|---|---|
| Call center and administrative departments | Integrated power and storage supports daily computer-based desk work |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2016 | Office worktables safety and strength requirements | |
|---|---|---|
| EN 1335-2:2018 | Office furniture stability strength and durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products test standard for strength and durability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units test standard for cabinets and pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal office furniture | |
| GB 28007-2011 | Safety requirements for children's and office furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 3325-2017: General technical requirements for metal office furniture; 3. GB 28007-2011: Safety requirements for children's and office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
